FLAMES News

Timeline of instrument status

The following table describes the events affecting the quality or the measurement of data obtained with FLAMES. Its content can be downloaded as a Comma Separated Values file. It is complete as of September 13th, 2020.

The Start Date column indicates when the event took place. Some events cannot be defined by a single instant, but extend over sometimes several days, weeks or months. Operation with the instrument may continue while the event occurs, in which case the Ongoing flag is set. If the event had ended, the Ongoing ? flag is lowered and End Date is given. The Type column indicates the characteristic(s) of the event: Earthquake, Maintenance, Upgrade, Element failure, Intervention, Pipeline installation at QC, Change of nominal values or thresholds, Modification of configuration file of this database, or Other. The Instrument Modes column indicates the affected mode. The column KPI indicates which quality control parameters identified as Key Performance Indicators (i.e., parameters following the most critical quantities) are affected; the column non-KPI indicates which other critical Quality Control parameters are affected. The Calibration Raw Types column indicates the raw types of the affected calibrations. The Calibration Breakpoint flag indicates if calibrations obtained before the event cannot be used for science data obtained after the event or if calibration data obtained after the event cannot be used with science data obtained before the event. The Comment column provides more details. The History column allows one to see possible past information on the entry.

The Quality Control pages for FLAMES can be accessed through the QC overview page

Announcements

On this page, we list the main changes that have affected the instrument and this web site.

  • June 25, 2024: Unfortunately, during calibrations, one of our fibres broke, with no light coming through, so we had to disable fibre 54 on plate 1. The List of broken fibers has been updated accordingly.
  • Jan 19, 2024: We have released a new version of FPOSS that now takes care of this avoidance zone automatically and does not assigne fibers to this area. Please update the FPOSS version when creating new OBs to avoid any issue.
  • Nov 10, 2023: We have recently analysed the defect in the field corrector lens of FLAMES. PIs can find some information in this brief summary. While we are working on a possible automatic solution in form of a FPOSS version which avoids the affected area automatically, PIs miht want to take care of this by themselves until such a automatic solution exists. Our recommendation is to avoid putting fibers between fibre 122 and 147 at a radius above 11.2, i.e. avoideing the outermost 1.3" between these buttons. This should minimize the impact on the science targets. We will post a updated FPOSS version once this has been implemented.
  • June 7, 2023: During a maintenance of the IT hardware and the following instrument startup, Medusa Fibre 84 on Plate2 got damaged and has been left out of service
  • Jan 29, 2023: The issues with the fibre gripper have seemingly been solved, so fibre 32 on plat 1 has been enabled again. The List of broken fibers has been updated.
  • Jan 2023:  Given repeated problems with the fibre positioner, we have (for now?) disabled fibre 32 on plate 1. We are working to resolve the issue and might enable it again. The  List of broken fibers has been updated (also in other inconsistent information).
  • Nov 2022: A crack in the corrector lens on the FLAMES focus has been detected (although it's even unclear whether it is a crack at this stage). The crack seems to be on one of the inner lens layers and protrudes around 7 cm into the lens (edge-to-edge, so we don't think it will grow further). We are trying to investigate whether this is in an area where fibers can overlap and/or whether there could be any effect on the spectra of those fibres (unsure how to measure this, but think this is very unlikely). Users should be aware that there could be SOME effect on fibres towards the very edge of the plate configurations.
  • January 15, 2021. FLAMES has been recommissioned and science operations have resumed.
  • August 31, 2019. FLAMES is not yet operational after its annual maintenance. News to be updated when the instrument is back.
  • October 14, 2018. An earth tremor on 23-Sept-2018 caused a shift in the direction perpendicular to the dispersion direction of -4 pixels in the HR grating only. An intervention on 13-Oct-2018 returned the grating to its original position. Science data should not be affected as long as calibrations  taken after the observations are used.
  • February 26, 2018. New version of the FLAMES User Manual for phase 1, P102 has been released. No changes wrt P101.
  • December 31, 2017. New version of the FLAMES User Manual for phase 2, P101 has been released.
  • December 31, 2017. Please see this link with information about the web-based phase 2 preparation software
  • July 11, 2016. New FPOSS version available. You are strongly encouraged to use the new version, which also works on Mac computers. More details here.
  • February 27, 2016. A new Giraffe readout mode will be availble in Visitor Mode only from Period 97. The mode is a high gain, low noise, slow readout mode that results in higher S/N (about a factor 2) only for faint targets, i.e. at the limit of the instrument sensitivity. The readout time of this slow mode is about 180s, whereas in the standard readout mode this is 45s. The ETC already includes the new readout mode in the Instrument Setup section. More details will be available here and in the User and Template manuals.
  • July 28, 2015. The new Giraffe spectral resolutions after the update in the focussing procedure in February have been characterised for all settings.
  • February 27, 2015. FLAMES news appeared on the ESO Science Newsletter (see here). Higher resolution versions of both figures can be found here and here.
  • February 9, 2015. On the afternoon of February 2, 2015, an update of the focussing procedure was implemented in FLAMES/Giraffe. This results in significant increase in both spectral resolution and sensitivity across all settings, although these enhencements vary from setting to setting. The Health Check monitor already reflects these variations (for an example, see here). The FLAMES/Giraffe ETC will soon reflect these modifications, once they are well understood at all settings. Users will be contacted by email with further details soon.
  • February 9, 2015. The cleaning of the Giraffe HR grating was again successfully performed at the end of January 2015, resulting in an increase in efficiency estimated to be in the range 10-20% for bluer settings.
  • December 13, 2014. List of broken fibers updated. After maintenance performed on the fiber positioner during the first week of December, three fibers were recovered. These are Medusa plate 2 RP2, FPS13; IFU sky plate 1, RP153, FPS192; and ARGUS sky, RP5, FPS1. The latter two were enabled before, but had low transmission.
  • August 20, 2014. List of broken fibers updated
  • May 20, 2014. Update of the ETC with improved efficiency measures at all settings. Estimates of signal-to-noise ratios (SNR) are now more accurate. Compared to the previous ETC version, the updated SNR are generally lower in blue settings and higher in red settings. Significant differences (less than a factor 2) are expected in the most blue and most red settings.
  • May 20, 2014. FPOSS manual update. Changes include the addition of two new sections: Known Features and Bugs, and Proper Motion. Also included is a clarification of the field of view for Guide Star selection.
  • Dec 18, 2012. Latest attempt to fix fiber 37 yielded 30% of the original transmission. Therefore the fiber will remain disabled until better results are reached or the fiber is replaced. Data obtained with the missing fiber can be reduced with the patched version of the FLAMES/UVES pipeline
  • Dec 17, 2012. FLAMES used to test sky-subtraction for the next generation of multi-fibers. Rodrigues et al. (SPIE, 2012) report correction below 1% using cross-beam switching or dual stare method. astro-ph link to be available soon.
  • Oct 6, 2012. The UVES fiber 37 on plate 2 is broken since Sep 11. Paranal is working to assess the severity of the problem and the actions to take. In the meanwhile, it was found that the FLAMES-UVES pipeline cannot reduce FLAMES-UVES data taken with a missing fiber. A new release of the pipeline will be made available as soon as possible to allow users to reduce their data. Users willing to re-discuss their observing strategy or to put their OBs on-hold until the problem is solved should contact USD.
  • May 11, 2011. GIRAFFE HR cleaned. Lost efficiency in the blue settings is now back.

  • May 1, 2011. List of broken fibers updated
  • Aug 25, 2010. A new web tool is available to reproduce Figure 16 and Figure 17 of the FLAMES user manual for a specific declination and wavelength.
  • Feb 17, 2010. The user manual has been updated with respect to the next P86. A new fast readout mode for GIRAFFE is offered to the community in visitor mode only. The manual can be retrieved at this web page.
  • Dec 23, 2009. The current FPOSS version is 1.42. This one is available on the following web page. FPOSS 1.42 must be used for all P85 OBs.
  • Dec 7, 2009. The GIRAFFE pipeline was upgraded to 2.8.1 on 2009-09-02. It may be found here.
  • Nov 4, 2009. UVES pipeline 4.4.8 supporting new red CCD (and old) data reduction.
  • Sep 1, 2009. FLAMES-UVES ETC updated with new QE curve for the upgraded MIT CCD.
  • Aug 28, 2009. All manuals updated for P85 including the GIRAFFE reduction cookbook. Please send comments to flames@eso.org. The main change for P85 is that FLAMES-UVES is more sensitive above 700-nm with less fringing and that the VLT guide star magnitude should now be ideally between mR=9 and 11.
  • Aug 26, 2009. The current UVES pipeline will NOT work with the upgraded CCD mosaic. This webpage will be updated when the release has been made.
  • Aug 26, 2009. The UVES red arm quantum efficiency ratio for the new/old MIT CCD is shown below (left panel) as derived in the lab and from standard stars. The EEV (bluer part of the red mosaic) is UNCHANGED. The MIT (redder part of the red mosaic) CCD "Nigel" was replaced with another MIT CCD "Zeus" in early July 2009 with superior Quantum Efficiency above 700-nm. The fringing is also much reduced;Plot (a) shows an extracted FLAMES-UVES flatfield order at about 900-nm with the Old CCD counts multiplied by 2.5 (same integration time). Plot(b) shows one normalised order of a stellar spectrum taken before and after the upgrade for standalone UVES.
  • Jun 25, 2009. Please remember that the ETC will only be upgraded with the new sensitivity values for the UVES (MIT) red-arm after the recommissioning in early July.When the new values are known they will be posted with a link on this webpage. Until then the current ETC should still be used.
  • Jun 23, 2009. Broken and low-throughput fibre page updated for Phase 2. See here for the current status.
  • Jun 19, 2009. FLAMES User manual updated for P84 Phase II. Go here for the document.
  • Jun 2, 2009. GIRAFFE pipline 2.8 released, see here for details.
  • May 1, 2009. Note that because of the upgrade to one of the UVES red CCDs, FLAMES-UVES will not be available until mid-July 2009. FLAMES-GIRAFFE observations continue as normal.
  • Feb 25, 2009. Important change for P84 proposals: For P84 for ARGUS only, the GIRAFFE settings L385.7, H379.0, H395.8 and H412.4 will be offered in Visitor Mode ONLY due to the difficulty in obtaining sufficient counts in the attached flatfields. Medusa and IFU are available in Service Mode for all settings. We hope in the future to improve the screen-flat lamp strength in the blue so that we can again offer Argus blue settings in Service Mode.
  • Dec 1-3, 2008. FLAMES 6th anniversary meeting; see the ESO Messenger article.The scientific programme with presentations is shown here. An open session at the end of the meeting provided several suggestions for improvements that will be investigated in due course.
  • May 25 2008 - Jul 10 2008 and for probably all the old CCD bias images at a lower level: History effect for Biases.The first bias in the normal 5 in the series was sometimes lower by up to about 2 ADU than the subsequent four images. This could cause errors in bias subtraction depending on the parameters used by the GIRAFFE pipeline. All service mode data have been re-reduced using the overscan region and not the master bias to remove this problem. Since2008-07-10 a 2-min gap has been added between the taking of the biases and the effect is no longer present. Note that the effect affected biases taken with the old CCD although at a lower level. See here for details.
  • March 1, 2008: The QE of the new detector to the existing one is shown below. A considerable improvement in the sensitivity is expected for wavelengths above 650nm.
  • March 16, 2007: Upgrade of GIRAFFE CCD discussed during the last IOT. Upgrade date still to be confirmed (P80 or P81).
  • March 03, 2007: FLAMES TCCD successfully replaced by the new generation TCCD.
  • April 25, 2005: GIRAFFE CCD decontamination.  See details.
  • November 23, 2004: Updated user manual for Science Verification and GTO observations
  • October 21, 2004: Please find here links to the Science Verification page and the Guarantied Time Observation projects.
  • 2004 Dec 7th. Sky flatfields that can be used to create a Solar Spectrum have been taken for all ARGUS HR and LR settings. They will soon be available in the ESO archive. The programme ID used was:60.A-9022(B). The Object name for all data is: SKY_spectrum_field. The dates taken were; 2004-11-26 (LR settings), 2004-11-30 and 2004-12-02(HR settings). January 5, 2005: Updated data for the AO instrument performance.
  • 2004 Nov 4th. Sky flatfields that can be used to create a Solar Spectrum have been taken for all Medusa HR and LR settings, plusFLAMES-UVES 520, 580, 860-nm. . They are available in the ESO archive.The programme ID used was: 60.A-9022(B). The Object name for all data is: SKY_spectrum_field. The dates taken were; 2004-09-26, 2004-09-28(HR settings) and 2004-10-11 (LR settings).
  • 2004 Sept 7th. Listof GIRAFFE settings which are reduced by the Pipeline on Paranal released.
  • 2004 July 29th. Visitor web pages updated.
  • 2004 July 19th. New versions of the Manuals released. Main changes are in the User Manual. See here.
  • 2004 July 1st. On-going efforts to characterise the velocity accuracy of FLAMES-UVES and FLAMES-GIRAFFE. Please email jsmoker@eso.org if you want details.
  • 2004 June 1. Version of the GIRAFFE pipeline on Paranal has been released since April 2004.
  • 2004 April 21. Version of the UVES pipeline released that will reduce both old-and-new format UVES data.See here for details.
  • 2004 April 7th P73 preparations. (1) The UVES red format has changed. This means that new FLAMES-UVES data will need to be reduced with the new UVES pipeline. (2) We have added a new column to the "binary FLAMES FIBRE Table" HDU3. This is called "FPD" which stands for "Fibre Position on Detector". It is the last column in the table which now reads "..... 700 870 X Y FPD". FPD is the same as FPS in all cases but ARGUS where the numbering is reversed.(3) We have added a new FITS keyword to the GIRAFFE headers. This is called "INS.EXP.MODE". This matches the "p2pp name" given in the following web pages for the HR grating and the LR grating.
  • 2004 March 14th. The approximate efficiencies of the new HR settings have been posted on the Giraffe web page; here.
  • 2004 March 4th. From P73 in Visitor Mode (VM) only, and from P74 in both Service Mode (SM) and Visitor mode, seven (7) new HR grating settings will be added. All but one of these work in higher order (therefore higher resolution but lower throughput -sometimes only 25 per cent) than the current settings. A further HR setting now covers both H-alpha and Li6707 (VM only P73, SM/VM P74). See here.
  • 2004 January 15th. New versions of the FLAMES user manual and Template reference guide available for P73. Main changes are that (1) there are now 24 HR grating settings as opposed to 22 previously,(2) The OB execution time is calculated automatically within p2pp and (3) ARGUS fast templates are available in p2pp for visitor mode.
  • 2003 October: New GIRAFFE higher-efficiency HR grating installed; available for P72. Note that this has lead to a decrease in resolution for some settings. See here for details.
  • 2003 July 21: FLAMES User Manual V1.1 released for P72.
  • 2003 July: ARGUS mode commissioned successfully; available for P72.For technical details cf. the (public) Commissioning Report
  • 2003 June: FACB 149 successfully installed and calibrated on plate 1 and 2
  • 2003 May: FLAMES commissioning data released
  • 2003 May: Giraffe BLDRS available at SourceForge
  • 2003 March: New Pre-Flames Survey Data Release
  • 2003 February/March: Early Start of Science Operation Period 71
  • 2003 January: Science Verification
  • 2002 December: Paranalization II
  • 2002 November: Paranalization I
  • 2002 October: Commissioning III
  • 2002 August: Commissioning II
  • 2002 June: Commissioning I
  • 2002 April: GIRAFFE installation at UT2
  • 2002 March: First Light UVES-fibres
  • 2002 February: Installation of OzPoz at UT2
  • 2001 December 19: Giraffe First Light in Garching Integration Hall.
  • 2001 December: Preliminary Acceptance Australia Fibre Positioner
  • 2001 November: Giraffe L-R grating arrived at ESO.
  • 2001 October: Commissioning Corrector at Kueyen.
  • 2001 September: Acceptance of the Corrector Optics
  • 2001 July: FLAMES User Workshop.
  • 2001 Jan: status presented at the ESO Wide Review 2001.
  • 2001 Jan: Giraffe optical table integrated on the enclosure.
  • 2000 Dec: Giraffe collimator and camera completed.
  • 2000 July: FLAMES Software FDR successfully passed.
  • 2000 May: FLAMES fully under construction.
