Used by Part of... System Altera source code Altera prog. file Schematic Description Releases Power consumption
PRIMA2 main 19.12.2002 GigaHp_B.pof
GigaHp_B.sof
Gigahp_rev_B.pdf GigaHp CS-P-1931-B VCC, 8.5 W
Comments R94, R95, R96, R70, JP4, R65, R66, R67, R68 are removed. Pin number 5 of U30 is disconnected.
