import "acscourseMount.idl";
Public Member Functions | |
| void | objfix (in double az, in double elev) raises (ACSErrTypeACSCourse::TargetOutOfRangeEx) |
| void | objfix (in double az, in double elev) raises (ACSErrTypeACSCourse::TargetOutOfRangeEx) |
Public Attributes | |
| readonly attribute ACS::ROdouble | cmdAz |
| readonly attribute ACS::ROdouble | cmdEl |
| readonly attribute ACS::ROdouble | actAz |
| readonly attribute ACS::ROdouble | actEl |
Detailed Description
Here we have a "complete" interface, including exceptions This time all properties are read only, because we set the values of azimuth and elevation via commands.
Member Function Documentation
| void ACSCOURSE_MOUNT::Mount3::objfix | ( | in double | az, | |
| in double | elev | |||
| ) | raises (ACSErrTypeACSCourse::TargetOutOfRangeEx) |
(Pre)sets a new non-moving position for the antenna. The position coordinates are given in azimuth and elevation. A callback is used to inform the caller when the antenna reaches the new position. If a new position is given before the previous one is reached then the previous callback immediately receives "aborted".
- Parameters:
-
az position azimuth (degree) elev position elevation (degree)
| void ACSCOURSE_MOUNT::Mount3::objfix | ( | in double | az, | |
| in double | elev | |||
| ) | raises (ACSErrTypeACSCourse::TargetOutOfRangeEx) |
(Pre)sets a new non-moving position for the antenna. The position coordinates are given in azimuth and elevation. A callback is used to inform the caller when the antenna reaches the new position. If a new position is given before the previous one is reached then the previous callback immediately receives "aborted".
- Parameters:
-
az position azimuth (degree) elev position elevation (degree)
Member Data Documentation
| readonly attribute ACS::ROdouble ACSCOURSE_MOUNT::Mount3::actAz |
Current actual azimuth (degree).
| readonly attribute ACS::ROdouble ACSCOURSE_MOUNT::Mount3::actEl |
Current actual elevation (degree).
| readonly attribute ACS::ROdouble ACSCOURSE_MOUNT::Mount3::cmdAz |
Current commanded azimuth (degree).
| readonly attribute ACS::ROdouble ACSCOURSE_MOUNT::Mount3::cmdEl |
Current commanded elevation (degree).
The documentation for this interface was generated from the following files:
