Plot
? |
Symb
? |
Source
* |
Average ? |
Thresholds ? |
N_
data |
QC1
parameter |
Data
downloads |
Remarks |
| method |
value |
unit |
method |
value |
| 1 |
• | QC1DB |
MEDIAN |
7.05e+04 |
ADU/Jy |
none | |
128 |
conver |
this |
last_yr |
all
|
conversion factor with PAH1 filter, pfov=0.0453 |
| 2 |
• | QC1DB |
MEDIAN |
5.76e+04 |
ADU/Jy |
none | |
56 |
conver |
this |
last_yr |
all
|
conversion factor with PAH2_2 filter, pfov=0.0453 |
| 3 |
• | QC1DB |
MEDIAN |
2.03e+04 |
ADU/Jy |
none | |
2 |
conver |
this |
last_yr |
all
|
conversion factor with ArIII filter, pfov=0.0453 |
| 4 |
• | QC1DB |
MEDIAN |
1.34e+05 |
ADU/Jy |
none | |
2 |
conver |
this |
last_yr |
all
|
conversion factor with J8.9 filter, pfov=0.0453 |
| 5 |
• | QC1DB |
MEDIAN |
2.01e+05 |
ADU/Jy |
none | |
84 |
conver |
this |
last_yr |
all
|
conversion factor with B10.7 filter, pfov=0.0453 |
| 6 |
• | QC1DB |
MEDIAN |
1.59e+04 |
ADU/Jy |
none | |
62 |
conver |
this |
last_yr |
all
|
conversion factor with NeII filter, pfov=0.0453 |
| |
|
*Data sources: QC1DB: QC1 database; LOCAL: local data source
|
Plot 1
scores: not implemented
| | data source: | visir_zp_img
(QC1 database) |
| dataset: | conver | • |
| median: | 7.05e+04 | ADU/Jy |
| thresholds: | none | |
| N_data plotted: | 128 |
| [click plot for closeup] |
Plot 2
scores: not implemented
| | data source: | visir_zp_img
(QC1 database) |
| dataset: | conver | • |
| median: | 5.76e+04 | ADU/Jy |
| thresholds: | none | |
| N_data plotted: | 56 |
| [click plot for closeup] |
Plot 3
scores: not implemented
| | data source: | visir_zp_img
(QC1 database) |
| dataset: | conver | • |
| median: | 2.03e+04 | ADU/Jy |
| thresholds: | none | |
| N_data plotted: | 2 |
| [click plot for closeup] |
Plot 4
scores: not implemented
| | data source: | visir_zp_img
(QC1 database) |
| dataset: | conver | • |
| median: | 1.34e+05 | ADU/Jy |
| thresholds: | none | |
| N_data plotted: | 2 |
| [click plot for closeup] |
Plot 5
scores: not implemented
| | data source: | visir_zp_img
(QC1 database) |
| dataset: | conver | • |
| median: | 2.01e+05 | ADU/Jy |
| thresholds: | none | |
| N_data plotted: | 84 |
| [click plot for closeup] |
Plot 6
scores: not implemented
| | data source: | visir_zp_img
(QC1 database) |
| dataset: | conver | • |
| median: | 1.59e+04 | ADU/Jy |
| thresholds: | none | |
| N_data plotted: | 62 |
| [click plot for closeup] |
Measurements of the conversion factor from imaging standard star
observations. Several N band filters are shown. Note that starting with
P95 only small-field (SF) observations with 0.0453 arcsec/pixel
are offered.
The conversion factor describes the conversion between ADU and Jy. It is
computed as: F(tot.observed) / F(model) [ADU/Jy], where F corresponds
to flux and F(model) is the model predicted flux of the standard star
from a catalog.
General information
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot.
If configured,
- data points belonging to the latest date are specially marked
- statistical averages are indicated by a solid line, and thresholds by broken lines
- outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
- "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
- you can download the data for each parameter set if the 'Data downloads' link shows up
|
