VIMOS trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2018-04-04T03:35:14 (UT)
  | now: 2024-11-14T01:12:23 (UT) muc03 QC pipeline: vimos-2.9.19 (installed 2016-03-17)
same group: X0_Y0 XX_YY XY_YX   Y0_TEMP
General news: NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
VIMOS news:
Report news:
DATE*: [?] 2018-03-28
no data | NLT
2018-03-29
no data | NLT
2018-03-30
no data | NLT
2018-03-31
no data | NLT
2018-04-01
no data | NLT
2018-04-02
no data | NLT
2018-04-03
no data | NLT
r...
Raw CAL displays:
no CAL raw files no CAL raw files no CAL raw files no CAL raw files no CAL raw files no CAL raw files no CAL raw files
P...
CAL product quality:
no CAL products no CAL products no CAL products no CAL products no CAL products no CAL products no CAL products

transfer   ngas [?]

scores&comments | history ... | plot tutorial ... | contact | HC_docu...                 daily/often; important to check     [?]
*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB MEDIAN 8.371 pix/mm VAL8.362,8.379 87 xx this | last_yr | all coefficient a(xx), Q2
2 QC1DB MEDIAN 8.389 pix/mm VAL8.382,8.395 85 xx this | last_yr | all coefficient a(xx), Q1
3 QC1DB MEDIAN 8.371 pix/mm VAL8.362,8.379 87 yy this | last_yr | all coefficient a(yy), Q2
4 QC1DB MEDIAN 8.389 pix/mm VAL8.381,8.394 85 yy this | last_yr | all coefficient a(yy), Q1
5 QC1DB MEDIAN 8.394 pix/mm VAL8.387,8.400 87 xx this | last_yr | all coefficient a(xx), Q3
6 QC1DB MEDIAN 8.393 pix/mm VAL8.386,8.399 85 xx this | last_yr | all coefficient a(xx), Q4
7 QC1DB MEDIAN 8.392 pix/mm VAL8.386,8.399 87 yy this | last_yr | all coefficient a(yy), Q3
8 QC1DB MEDIAN 8.392 pix/mm VAL8.385,8.398 85 yy this | last_yr | all coefficient a(yy), Q4
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: 7|
data source:vimos_mask2ccd
(QC1 database)
dataset:xx
median:8.371pix/mm
fixed thresholds:8.362...8.379pix/mm
N_data plotted:87
[click plot for closeup]
Plot 2
scores: 7|
data source:vimos_mask2ccd
(QC1 database)
dataset:xx
median:8.389pix/mm
fixed thresholds:8.382...8.395pix/mm
N_data plotted:85
[click plot for closeup]
Plot 3
scores: 7|
data source:vimos_mask2ccd
(QC1 database)
dataset:yy
median:8.371pix/mm
fixed thresholds:8.362...8.379pix/mm
N_data plotted:87
[click plot for closeup]
Plot 4
scores: 7|
data source:vimos_mask2ccd
(QC1 database)
dataset:yy
median:8.389pix/mm
fixed thresholds:8.381...8.394pix/mm
N_data plotted:85
[click plot for closeup]
Plot 5
scores: 7|
data source:vimos_mask2ccd
(QC1 database)
dataset:xx
median:8.394pix/mm
fixed thresholds:8.387...8.4pix/mm
N_data plotted:87
[click plot for closeup]
Plot 6
scores: 7|
data source:vimos_mask2ccd
(QC1 database)
dataset:xx
median:8.393pix/mm
fixed thresholds:8.386...8.399pix/mm
N_data plotted:85
[click plot for closeup]
Plot 7
scores: 7|
data source:vimos_mask2ccd
(QC1 database)
dataset:yy
median:8.392pix/mm
fixed thresholds:8.386...8.399pix/mm
N_data plotted:87
[click plot for closeup]
Plot 8
scores: 7|
data source:vimos_mask2ccd
(QC1 database)
dataset:yy
median:8.392pix/mm
fixed thresholds:8.385...8.398pix/mm
N_data plotted:85
[click plot for closeup]
This plot

Trending plots for monitoring the coefficients of the mask to CCD transformation.

The transformation is as follows:
X = a(xx)*x + a(xy)*y + x(0)
Y = a(yx)*x + a(yy)*y + y(0)
with (x,y) being mask coordinates in mm and (X,Y) CCD coordinates in pixel. X direction is along the slit orientation, y direction is perpendicular to the slits (i.e. in dispersion direction).

These trending plots show the time evolution of the matrix coefficients a(xx), a(xy), a(yx), and a(yy). The diagonal coefficients a(xx) and a(yy) give the scale factor between mask and CCD (near 8.4 pixel/mm). Variations are mainly cause by temperature changes, the empirical tolerance is around +/- 0.006 pixel/mm. The coefficients a(xy) and a(yx) give the rotation and should be near zero. The tolerance is +/- 0.005 pixel/mm around the empirical average. The procedure in case of violation of the thresholds is described on the SciOps Wiki pages.

Template ID: img_tec_MaskToCcd. Pipeline recipe: vmmasktoccd.


General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
