Plot
? |
Symb
? |
Source
* |
Average ? |
Thresholds ? |
N_
data |
QC1
parameter |
Data
downloads |
Remarks |
| method |
value |
unit |
method |
value |
| 1 |
• | QC1DB |
MEDIAN |
207 |
num |
VAL | 206,210 |
13 |
trace2_central |
this |
last_yr |
all
|
Q2, central fibre number |
| 2 |
• | QC1DB |
MEDIAN |
200 |
num |
VAL | 198,202 |
13 |
trace2_central |
this |
last_yr |
all
|
Q1, central fibre number |
| 3 |
• | QC1DB |
MEDIAN |
204 |
num |
VAL | 202,206 |
13 |
trace2_central |
this |
last_yr |
all
|
Q3, central fibre number |
| 4 |
• | QC1DB |
MEDIAN |
200 |
num |
VAL | 198,202 |
13 |
trace2_central |
this |
last_yr |
all
|
Q4, central fibre number |
| |
|
*Data sources: QC1DB: QC1 database; LOCAL: local data source
|
Plot 1
scores:  2|
| | data source: | vimos_ifu_score
(QC1 database) |
| dataset: | trace2_central | • |
| median: | 207 | num |
| fixed thresholds: | 206...210 | num |
| N_data plotted: | 13 |
| [click plot for closeup] |
Plot 2
scores: 2|
| | data source: | vimos_ifu_score
(QC1 database) |
| dataset: | trace2_central | • |
| median: | 200 | num |
| fixed thresholds: | 198...202 | num |
| N_data plotted: | 13 |
| [click plot for closeup] |
Plot 3
scores: 2|
| | data source: | vimos_ifu_score
(QC1 database) |
| dataset: | trace2_central | • |
| median: | 204 | num |
| fixed thresholds: | 202...206 | num |
| N_data plotted: | 13 |
| [click plot for closeup] |
Plot 4
scores: 2|
| | data source: | vimos_ifu_score
(QC1 database) |
| dataset: | trace2_central | • |
| median: | 200 | num |
| fixed thresholds: | 198...202 | num |
| N_data plotted: | 13 |
| [click plot for closeup] |
Trending plot for the central fibre in IFU calibrations.
The central fibre number should vary only by about +/- 2.
Setting HR_orange is usually measured daily; other settings only when science frames have been observed.
For LR grisms, only data with IFU shutter OFF are plotted.
Template ID: ifu_cal_DayCalib (daytime Health Checks), ifu_cal_NightCalib
(attached night-time). Pipeline recipe: vmifucalib.
General information
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot.
If configured,
- data points belonging to the latest date are specially marked
- statistical averages are indicated by a solid line, and thresholds by broken lines
- outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
- "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
- you can download the data for each parameter set if the 'Data downloads' link shows up
|
