GRAVITY trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2017-05-16T18:29:55 (UT)
  | now: 2024-11-23T17:12:20 (UT) muc05 QC pipeline: gravity-1.0.2 (installed 2017-03-23)
same group: avg coher_split mincoher_split coher_comb mincoher_comb
General news: NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
GRAVITY news:
Report news:
DATE*: [?] 2024-11-16
report | NLT 		2024-11-17
report | NLT 		2024-11-18
report | NLT 		2024-11-19
report | NLT 		2024-11-20
report | NLT 		2024-11-21
report | NLT 		2024-11-22
report | NLT
r...
Raw CAL displays:
raw raw raw raw raw raw raw
P...
CAL product quality:
products products products products products products products

transfer   ngas [?]

scores&comments | history ... | plot tutorial ... | contact               [?] 		*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?		 Symb
?		 Source
*		 Average ? Thresholds ? N_
data		 QC1
parameter		 Data
downloads		 Remarks
method value unit method value
1 •QC1DB MEDIAN 0.959 none VAL0.9,1.0 10 coherence_avg_ft this | last_yr | all average coherence of P2VM, SPLIT polarisation, Fringe Tracker (FT) detector
2 •QC1DB MEDIAN 0.921 none VAL0.9,1.0 10 coherence_avg_sc this | last_yr | all average coherence of P2VM, SPLIT polarisation, Science Camera (SC) detector
3 •QC1DB MEDIAN 0.941 none VAL0.9,1.0 24 coherence_avg_ft this | last_yr | all average coherence of P2VM, COMBINED polarisation, Fringe Tracker (FT) detector
4 •QC1DB MEDIAN 0.928 none VAL0.9,1.0 24 coherence_avg_sc this | last_yr | all average coherence of P2VM, COMBINED polarisation, Science Camera (SC) detector
5 •QC1DB MEDIAN 0.016 none VAL0.013,0.025 10 phaserms_ft this | last_yr | all phase RMS of P2VM, SPLIT polarisation, Fringe Tracker (FT) detector
6 •QC1DB MEDIAN 0.0185 none VAL0.013,0.025 10 phaserms_sc this | last_yr | all phase RMS of P2VM, SPLIT polarisation, Science Camera (SC) detector
7 •QC1DB MEDIAN 0.016 none VAL0.013,0.025 24 phaserms_ft this | last_yr | all phase RMS of P2VM, COMBINED polarisation, Fringe Tracker (FT) detector
8 •QC1DB MEDIAN 0.0166 none VAL0.013,0.029 24 phaserms_sc this | last_yr | all phase RMS of P2VM, COMBINED polarisation, Science Camera (SC) detector
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: 2|
data source:gravity_p2vm
(QC1 database)
dataset:coherence_avg_ft•
median:0.959none
fixed thresholds:0.9...1.0none
N_data plotted:10
[click on plot for closeup]
Plot 2
scores: 2|
data source:gravity_p2vm
(QC1 database)
dataset:coherence_avg_sc•
median:0.921none
fixed thresholds:0.9...1.0none
N_data plotted:10
[click on plot for closeup]
Plot 3
scores: 2|
data source:gravity_p2vm
(QC1 database)
dataset:coherence_avg_ft•
median:0.941none
fixed thresholds:0.9...1.0none
N_data plotted:24
[click on plot for closeup]
Plot 4
scores: 2|
data source:gravity_p2vm
(QC1 database)
dataset:coherence_avg_sc•
median:0.928none
fixed thresholds:0.9...1.0none
N_data plotted:24
[click on plot for closeup]
Plot 5
scores: 2|
data source:gravity_p2vm
(QC1 database)
dataset:phaserms_ft•
median:0.016none
fixed thresholds:0.013...0.025none
N_data plotted:10
[click on plot for closeup]
Plot 6
scores: 2|
data source:gravity_p2vm
(QC1 database)
dataset:phaserms_sc•
median:0.0185none
fixed thresholds:0.013...0.025none
N_data plotted:10
[click on plot for closeup]
Plot 7
scores: 2|
data source:gravity_p2vm
(QC1 database)
dataset:phaserms_ft•
median:0.016none
fixed thresholds:0.013...0.025none
N_data plotted:24
[click on plot for closeup]
Plot 8
scores: 2|
data source:gravity_p2vm
(QC1 database)
dataset:phaserms_sc•
median:0.0166none
fixed thresholds:0.013...0.029none
N_data plotted:24
[click on plot for closeup]
This plot

Trending plots for pixel-to-visibility-maxtrix (P2VM) calibrations. This plot contains values that are averaged over the six baselines.

Note about LOW resolution: with pipeline version 1.2.x, installed 2019-03-25 for QC, some QC parameters for P2VM do not give meaningful values. This includes the phase RMS. Plotting of these parameters and scoring has therefore been stopped for LOW resolution.

General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
  • you can download the data for each parameter set if the 'Data downloads' link shows up
