CRIRES trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2014-07-22T11:32:50 (UT)
  | now: 2024-11-08T17:34:16 (UT) muc01 QC pipeline: crire-2.3.2 (installed 2014-03-18)
same group: darkmed ron_raw
General news: NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
CRIRES news:
Report news:
DATE*: [?] 2024-11-01
no data | NLT 		2024-11-02
no data | NLT 		2024-11-03
no data | NLT 		2024-11-04
no data | NLT 		2024-11-05
no data | NLT 		2024-11-06
report | NLT 		2024-11-07
no data | NLT
r...
Raw CAL displays:
no CAL raw files no CAL raw files no CAL raw files no CAL raw files no CAL raw files raw no CAL raw files
P...
CAL product quality:
no CAL products no CAL products no CAL products no CAL products no CAL products products no CAL products
  last OPSLOG data:
2014-07-16*
last files ...
[an error occurred while processing this directive]
monitor

scores&comments | FULL | history ... | plot tutorial ... | contact                 daily/often; important to check     [?] 		*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?		 Symb
?		 Source
*		 OPS?
**		 Average ? Thresholds ? N_
data		 QC1
parameter		 Data
downloads		 Remarks
method value unit method value
1 •QC1DB yes (1) MEDIAN 0.583 ADU VAL-0.5,1.5 86 darkmed this | last_yr | all median dark level, chip 1, DIT=1
2 •QC1DB yes (1) MEDIAN 0.833 ADU VAL0,2.5 86 darkmed this | last_yr | all median dark level, chip 2, DIT=1
3 •QC1DB yes (1) MEDIAN 0.583 ADU VAL-0.5,2.0 86 darkmed this | last_yr | all median dark level, chip 3, DIT=1
4 •QC1DB yes (1) MEDIAN 0.667 ADU VAL0,2.0 86 darkmed this | last_yr | all median dark level, chip 4, DIT=1
5 •QC1DB yes (1) MEDIAN 9.54 ADU VAL0,20 90 darkmed this | last_yr | all median dark level, chip 1, DIT=300
6 •QC1DB yes (1) MEDIAN 21.9 ADU VAL8.5,40 90 darkmed this | last_yr | all median dark level, chip 2, DIT=300
7 •QC1DB yes (1) MEDIAN 14.8 ADU VAL4,37 90 darkmed this | last_yr | all median dark level, chip 3, DIT=300
8 •QC1DB yes (1) MEDIAN 11.6 ADU VAL0,35 90 darkmed this | last_yr | all median dark level, chip 4, DIT=300
*Data sources: QC1DB: QC1 database; LOCAL: local text file | **OPS: OPSLOG data are included
Plot 1
scores: 8|
data source:crires_dark
(QC1 database)
dataset:darkmed•
median:0.583ADU
fixed thresholds:-0.5...1.5ADU
N_data plotted:86
[click on plot for closeup]
Plot 2
scores: 8|
data source:crires_dark
(QC1 database)
dataset:darkmed•
median:0.833ADU
fixed thresholds:0...2.5ADU
N_data plotted:86
[click on plot for closeup]
Plot 3
scores: 8|
data source:crires_dark
(QC1 database)
dataset:darkmed•
median:0.583ADU
fixed thresholds:-0.5...2.0ADU
N_data plotted:86
[click on plot for closeup]
Plot 4
scores: 8|
data source:crires_dark
(QC1 database)
dataset:darkmed•
median:0.667ADU
fixed thresholds:0...2.0ADU
N_data plotted:86
[click on plot for closeup]
Plot 5
scores: 8|
data source:crires_dark
(QC1 database)
dataset:darkmed•
median:9.54ADU
fixed thresholds:0...20ADU
N_data plotted:90
[click on plot for closeup]
Plot 6
scores: 8|
data source:crires_dark
(QC1 database)
dataset:darkmed•
median:21.9ADU
fixed thresholds:8.5...40ADU
N_data plotted:90
[click on plot for closeup]
Plot 7
scores: 8|
data source:crires_dark
(QC1 database)
dataset:darkmed•
median:14.8ADU
fixed thresholds:4...37ADU
N_data plotted:90
[click on plot for closeup]
Plot 8
scores: 8|
data source:crires_dark
(QC1 database)
dataset:darkmed•
median:11.6ADU
fixed thresholds:0...35ADU
N_data plotted:90
[click on plot for closeup]
This plot

Trending plot for the median level in CRIRES DARK exposures.

The trending shows median levels from DIT=1sec and DIT=300sec exposures for all four chips.



General information

Click on any of the plots to see a close-up version.

If applicable, the latest values from Paranal ops logs are plotted as blue dots. More information about those values, including a download option, is available in the OPS column.

The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
  • you can download the data for each parameter set if the 'Data downloads' link shows up
