BulkDataSenderImpl< TSenderCallback > Class Template Reference
#include <bulkDataSenderImpl.h>
Public Member Functions | |
| BulkDataSenderImpl (const ACE_CString &name, maci::ContainerServices *containerServices) | |
| virtual | ~BulkDataSenderImpl () |
| void | cleanUp () |
| virtual void | connect (bulkdata::BulkDataReceiver_ptr receiverObj_p) |
| virtual void | disconnect () |
| virtual AcsBulkdata::BulkDataSender < TSenderCallback > * | getSender () |
| virtual void | startSend ()=0 |
| virtual void | paceData ()=0 |
| virtual void | stopSend ()=0 |
Private Attributes | |
| maci::ContainerServices * | containerServices_p |
| AcsBulkdata::BulkDataSender < TSenderCallback > | sender |
| bulkdata::BulkDataReceiver_ptr | receiverObj_m |
template<class TSenderCallback = BulkDataSenderDefaultCallback>
class BulkDataSenderImpl< TSenderCallback >
Constructor & Destructor Documentation
| BulkDataSenderImpl< TSenderCallback >::BulkDataSenderImpl | ( | const ACE_CString & | name, | |
| maci::ContainerServices * | containerServices | |||
| ) |
Constructor
- Parameters:
-
poa poa which will activate this and also all other components name component name
| virtual BulkDataSenderImpl< TSenderCallback >::~BulkDataSenderImpl | ( | ) | [virtual] |
Destructor
Member Function Documentation
| void BulkDataSenderImpl< TSenderCallback >::cleanUp | ( | ) | [virtual] |
Called after the last functional call to the component has finished. The component should then orderly release resources etc. If this method is overwritten in a subclass, the developer has to make sure that all cleanup performed by the implementation of the base class take place. The best way to do this is to call the implementation of the base itself explicitly, as would be done implicitly in a destructor chain.
- Returns:
- void
Reimplemented from acscomponent::ACSComponentImpl.
Reimplemented in BulkDataSenderDistrImpl< TSenderCallback >.
| virtual void BulkDataSenderImpl< TSenderCallback >::connect | ( | bulkdata::BulkDataReceiver_ptr | receiverObj_p | ) | [virtual] |
Negotiate and initialize connection with the Sender object.
- Parameters:
-
receiver reference of the Receiver Component.
- Exceptions:
-
ACSBulkDataError::AVConnectErrorEx
- Returns:
- void
| virtual void BulkDataSenderImpl< TSenderCallback >::disconnect | ( | ) | [virtual] |
- Exceptions:
-
ACSBulkDataError::AVDisconnectErrorEx
| virtual AcsBulkdata::BulkDataSender<TSenderCallback>* BulkDataSenderImpl< TSenderCallback >::getSender | ( | ) | [inline, virtual] |
References BulkDataSenderImpl< TSenderCallback >::sender.
| virtual void BulkDataSenderImpl< TSenderCallback >::paceData | ( | ) | [pure virtual] |
Sends data to the Receiver calling the receive_frame() method on the Receiver side. This method must be overriden by the user to send his own data.
- Parameters:
-
size buffer size of the sent data.
- Exceptions:
-
ACSBulkDataError::AVPaceDataErrorEx
- Returns:
- void
Implemented in BulkDataSenderDistrImpl< TSenderCallback >, BulkDataSenderEx1Impl, BulkDataSenderEx2Impl, BulkDataSenderEx3Impl, BulkDataSenderNotifImpl, BulkDataSenderPerfImpl, and BulkDataSenderThreadImpl.
| virtual void BulkDataSenderImpl< TSenderCallback >::startSend | ( | ) | [pure virtual] |
Calls the Receiver handle_start() method once the connection is established.
- Exceptions:
-
ACSBulkDataError::AVStartSendErrorEx
- Returns:
- void
Implemented in BulkDataSenderDistrImpl< TSenderCallback >, BulkDataSenderEx1Impl, BulkDataSenderEx2Impl, BulkDataSenderEx3Impl, BulkDataSenderNotifImpl, BulkDataSenderPerfImpl, and BulkDataSenderThreadImpl.
| virtual void BulkDataSenderImpl< TSenderCallback >::stopSend | ( | ) | [pure virtual] |
Calls the Receiver handle_stop() method.
- Exceptions:
-
ACSBulkDataError::AVStopSendErrorEx
- Returns:
- void
Implemented in BulkDataSenderDistrImpl< TSenderCallback >, BulkDataSenderEx1Impl, BulkDataSenderEx2Impl, BulkDataSenderEx3Impl, BulkDataSenderNotifImpl, BulkDataSenderPerfImpl, and BulkDataSenderThreadImpl.
Member Data Documentation
maci::ContainerServices* BulkDataSenderImpl< TSenderCallback >::containerServices_p [private] |
Pointer to the dataProtocol on which the send_frame(...) method is called in order to actually send data.
bulkdata::BulkDataReceiver_ptr BulkDataSenderImpl< TSenderCallback >::receiverObj_m [private] |
AcsBulkdata::BulkDataSender<TSenderCallback> BulkDataSenderImpl< TSenderCallback >::sender [private] |
Referenced by BulkDataSenderImpl< TSenderCallback >::getSender().
The documentation for this class was generated from the following file:
