import "bulkDataReceiver.idl";
Public Member Functions | |
| void | openReceiver () raises (ACSBulkDataError::AVOpenReceiverErrorEx) |
| void | openReceiverStream (in string stream_name) raises (ACSBulkDataError::AVOpenReceiverErrorEx) |
| BulkDataReceiverConfig | getReceiverConfig () raises (ACSBulkDataError::AVReceiverConfigErrorEx) |
| void | closeReceiver () raises (ACSBulkDataError::AVCloseReceiverErrorEx) |
| void | closeReceiverStream (in string stream_name) raises (ACSBulkDataError::AVCloseReceiverErrorEx) |
| ACSErr::Completion | getCbStatus (in unsigned long flowNumber) raises (ACSBulkDataError::AVInvalidFlowNumberEx, ACSBulkDataError::AVFlowEndpointErrorEx) |
| void | setTimeout (in unsigned long flowNumber, in unsigned long timeout) raises (ACSBulkDataError::AVInvalidFlowNumberEx, ACSBulkDataError::AVFlowEndpointErrorEx) |
| void | setRecvName (in string recvName) raises (ACSBulkDataError::AVSetReceiverNameErrorEx) |
| void | subscribeNotification (in ACS::CBvoid notifCb) raises (ACSBulkDataError::AVNotificationMechanismErrorEx) |
| void | fwdData2UserCB (in boolean enable) |
Detailed Description
Defines the interface for the Bulk Data Receiver Component
Member Function Documentation
| void bulkdata::BulkDataReceiver::closeReceiver | ( | ) | raises (ACSBulkDataError::AVCloseReceiverErrorEx) |
Closes connection.......
- Returns:
- void
| void bulkdata::BulkDataReceiver::closeReceiverStream | ( | in string | stream_name | ) | raises (ACSBulkDataError::AVCloseReceiverErrorEx) |
| void bulkdata::BulkDataReceiver::fwdData2UserCB | ( | in boolean | enable | ) |
Enable or disable that data are sent/forwarded to the user's CB. By default this is enable. This operation has to be use with caution for debugging purposes only!!! The operation has effect only if it is ivoked after the connection with the receiver has been established i.e. the callback object has been created !!
- Parameters:
-
enable true -> data will be sent to the user's CB, false -> data will *not* be sent to the user's CB,
- Returns:
- void
| ACSErr::Completion bulkdata::BulkDataReceiver::getCbStatus | ( | in unsigned long | flowNumber | ) | raises (ACSBulkDataError::AVInvalidFlowNumberEx, ACSBulkDataError::AVFlowEndpointErrorEx) |
Get callback status
- Returns:
- ACSErr::Completion
| BulkDataReceiverConfig bulkdata::BulkDataReceiver::getReceiverConfig | ( | ) | raises (ACSBulkDataError::AVReceiverConfigErrorEx) |
This property is the Receiver Steam End Point.
| void bulkdata::BulkDataReceiver::openReceiver | ( | ) | raises (ACSBulkDataError::AVOpenReceiverErrorEx) |
Opens connection creating an out-of-bound channel using TAO A/V services. It creates the Receiver Stream End Point and Flow End Point for the connection with the Sender. The Receiver Stream End Point can be retrieved as an attribute.
- Returns:
- void
| void bulkdata::BulkDataReceiver::openReceiverStream | ( | in string | stream_name | ) | raises (ACSBulkDataError::AVOpenReceiverErrorEx) |
| void bulkdata::BulkDataReceiver::setRecvName | ( | in string | recvName | ) | raises (ACSBulkDataError::AVSetReceiverNameErrorEx) |
Set receiver name in receiver callback
- Parameters:
-
recName receiver name.
- Returns:
- void
| void bulkdata::BulkDataReceiver::setTimeout | ( | in unsigned long | flowNumber, | |
| in unsigned long | timeout | |||
| ) | raises (ACSBulkDataError::AVInvalidFlowNumberEx, ACSBulkDataError::AVFlowEndpointErrorEx) |
Set receiver timeout
- Returns:
- void
| void bulkdata::BulkDataReceiver::subscribeNotification | ( | in ACS::CBvoid | notifCb | ) | raises (ACSBulkDataError::AVNotificationMechanismErrorEx) |
Subscribe to the Notification Mechanism
- Parameters:
-
notifCb receiver name.
- Returns:
- void
The documentation for this interface was generated from the following file:
