import "acscourseMount.idl";
Public Member Functions | |
| void | objfix (in double az, in double elev) raises (ACSErrTypeACSCourse::TargetOutOfRangeEx) |
| void | objfix (in double az, in double elev) |
Public Attributes | |
| readonly attribute ACS::ROdouble | cmdAz |
| readonly attribute ACS::ROdouble | cmdEl |
| readonly attribute ACS::ROdouble | actAz |
| readonly attribute ACS::ROdouble | actEl |
Detailed Description
Nearly identical to Mount1 except for the fact that this example publishes/consumes events from an event channel and that exception handling has been ommitted.
Member Function Documentation
| void ACSCOURSE_MOUNT::Mount5::objfix | ( | in double | az, | |
| in double | elev | |||
| ) | raises (ACSErrTypeACSCourse::TargetOutOfRangeEx) |
(Pre)sets a new non-moving position for the antenna. The position coordinates are given in azimuth and elevation. A callback is used to inform the caller when the antenna reaches the new position. If a new position is given before the previous one is reached then the previous callback immediately receives "aborted".
- Parameters:
-
az position azimuth (degree) elev position elevation (degree)
| void ACSCOURSE_MOUNT::Mount5::objfix | ( | in double | az, | |
| in double | elev | |||
| ) |
(Pre)sets a new non-moving position for the antenna. The position coordinates are given in azimuth and elevation.
- Parameters:
-
az position azimuth (degree) elev position elevation (degree)
Member Data Documentation
| readonly attribute ACS::ROdouble ACSCOURSE_MOUNT::Mount5::actAz |
Current actual azimuth (degree).
| readonly attribute ACS::ROdouble ACSCOURSE_MOUNT::Mount5::actEl |
Current actual elevation (degree).
| readonly attribute ACS::ROdouble ACSCOURSE_MOUNT::Mount5::cmdAz |
Current commanded azimuth (degree).
| readonly attribute ACS::ROdouble ACSCOURSE_MOUNT::Mount5::cmdEl |
Current commanded elevation (degree).
The documentation for this interface was generated from the following files:
