UVES trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2024-11-21T19:19:58 (UT)
  | now: 2024-11-22T00:03:35 (UT) muc02 QC pipeline: uves-6.1.11 (installed 2023-06-22)
same group: dark linearity gain duty_cycle
General news: NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
UVES news:
Report news:
DATE*: [?] 2024-11-14
report | NLT
2024-11-15
report | NLT
2024-11-16
report | NLT
2024-11-17
report | NLT
2024-11-18
report | NLT
2024-11-19
report | NLT
2024-11-20
report | NLT
2024-11-21
no data | NLT
r...
Raw CAL displays:
raw raw raw raw raw raw raw no CAL raw files
P...
CAL product quality:
products products products products products products products no CAL products

transfer   ngas [?]

scores&comments | FULL | history ... | plot tutorial ... | contact | HC_docu... | quality events...               [?]
*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB MEDIAN 45.6 ADU none  88 duty_cycle this | last_yr | all duty cycle in BIAS, readout mode 225kHz,1x1,low; BLUE CCD
2 QC1DB MEDIAN 48.4 ADU none  86 duty_cycle this | last_yr | all duty cycle in BIAS, readout mode 50kHz,2x2,high; BLUE CCD
3 QC1DB MEDIAN   ADU none  0 duty_cycle this | last_yr | all duty cycle in BIAS, readout mode 625kHz (ultrafast),1x1,low; BLUE CCD
4 QC1DB MEDIAN 46.8 ADU none  107 duty_cycle this | last_yr | all duty cycle in BIAS, readout mode 225kHz,1x1,low; RED CCD
5 QC1DB MEDIAN 52.4 ADU none  96 duty_cycle this | last_yr | all duty cycle in BIAS, readout mode 50kHz,2x2,high; RED CCD
6 QC1DB MEDIAN 19.4 ADU none  13 duty_cycle this | last_yr | all duty cycle in BIAS, readout mode 625kHz (ultrafast),1x1,low; RED CCD
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: not implemented
data source:uves_bias
(QC1 database)
dataset:duty_cycle
median:45.6ADU
thresholds:none
N_data plotted:88
[click plot for closeup]
Plot 2
scores: not implemented
data source:uves_bias
(QC1 database)
dataset:duty_cycle
median:48.4ADU
thresholds:none
N_data plotted:86
[click plot for closeup]
Plot 3
scores: not implemented
data source:uves_bias
(QC1 database)
dataset:duty_cycle
median:no dataADU
thresholds:none
N_data plotted:0
[click plot for closeup]
Plot 4
scores: not implemented
data source:uves_bias
(QC1 database)
dataset:duty_cycle
median:46.8ADU
thresholds:none
N_data plotted:107
[click plot for closeup]
Plot 5
scores: not implemented
data source:uves_bias
(QC1 database)
dataset:duty_cycle
median:52.4ADU
thresholds:none
N_data plotted:96
[click plot for closeup]
Plot 6
scores: not implemented
data source:uves_bias
(QC1 database)
dataset:duty_cycle
median:19.4ADU
thresholds:none
N_data plotted:13
[click plot for closeup]
This plot

This is a trending report for the duty cycle calculated on the UVES BIAS frames.
We monitor here the time to store a UVES frame for the different setups which has to be taken into account when calculating overheads.
From user manual in s:

  1. BLUE Chip 2x2/1pt/50kHz: 48
  2. BLUE Chip 1pt/225kHz: 46
  3. BLUE Chip 2pts/625kHz: 22
  4. RED Chip 2x2/2pts/50kHz: 52
  5. RED Chip 2pts/225kHz: 47
  6. RED Chip 4pts/625kHz: 19

General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
