Plot
? |
Symb
? |
Source
* |
Average ? |
Thresholds ? |
N_
data |
QC1
parameter |
Data
downloads |
Remarks |
| method |
value |
unit |
method |
value |
| 1 |
• | QC1DB |
MEDIAN |
0.482 |
ADU |
VAL | 0,1 |
68 |
struct_r |
this |
last_yr |
all
|
Chip 1, 100Kps/2ports/high_gain, 2x2 (only non-zero values are shown) |
| 2 |
• | QC1DB |
MEDIAN |
0.589 |
ADU |
VAL | 0,1 |
70 |
struct_r |
this |
last_yr |
all
|
Chip 2, 100Kps/2ports/high_gain, 2x2 (only non-zero values are shown) |
| 3 |
• | QC1DB |
MEDIAN |
0.473 |
ADU |
VAL | 0,1 |
75 |
struct_r |
this |
last_yr |
all
|
Chip 1, 200Kps/2ports/low_gain, 2x2 (only non-zero values are shown) |
| 4 |
• | QC1DB |
MEDIAN |
0.497 |
ADU |
VAL | 0,1 |
75 |
struct_r |
this |
last_yr |
all
|
Chip 2, 200Kps/2ports/low_gain, 2x2 (only non-zero values are shown) |
| |
|
*Data sources: QC1DB: QC1 database; LOCAL: local data source
|
Plot 1
scores:  3|
| | data source: | fors2_bias
(QC1 database) |
| dataset: | struct_r | • |
| median: | 0.482 | ADU |
| fixed thresholds: | 0...1 | ADU |
| N_data plotted: | 68 |
| [click plot for closeup] |
Plot 2
scores: 3|
| | data source: | fors2_bias
(QC1 database) |
| dataset: | struct_r | • |
| median: | 0.589 | ADU |
| fixed thresholds: | 0...1 | ADU |
| N_data plotted: | 70 |
| [click plot for closeup] |
Plot 3
scores: 3|
| | data source: | fors2_bias
(QC1 database) |
| dataset: | struct_r | • |
| median: | 0.473 | ADU |
| fixed thresholds: | 0...1 | ADU |
| N_data plotted: | 75 |
| [click plot for closeup] |
Plot 4
scores: 3|
| | data source: | fors2_bias
(QC1 database) |
| dataset: | struct_r | • |
| median: | 0.497 | ADU |
| fixed thresholds: | 0...1 | ADU |
| N_data plotted: | 75 |
| [click plot for closeup] |
The population standard deviation of the pixel values of the first input raw bias is computed. This is the combination of structure, fixed pattern noise, and read out noise. The read out noise and the fixed pattern noise contributions are then quadratically subtracted.
Details
can be found in the plot tutorial.
DB Name: fors2_bias
TPL.ID: img_cal_bias
Fits header keyword: QC.BIAS.STRUCT
QC1 DB parameter: struct_r
General information
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot.
If configured,
- data points belonging to the latest date are specially marked
- statistical averages are indicated by a solid line, and thresholds by broken lines
- outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
- "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
- you can download the data for each parameter set if the 'Data downloads' link shows up
|
