Plot ? |
Symb ? |
Source * |
Average ? |
Thresholds ? |
N_ data |
QC1 parameter |
Data downloads |
Remarks |
method |
value |
unit |
method |
value |
1 |
| QC1DB |
MEDIAN |
1.78 |
pixels |
VAL | 0.0,25.0 |
207 |
qc_center_offset |
this |
last_yr |
all
|
distance of detected PSF star from nominal field center (pixels) |
|
*Data sources: QC1DB: QC1 database; LOCAL: local data source
|
Plot 1 scores: 12|
| data source: | sinfoni_psf (QC1 database) |
dataset: | qc_center_offset | |
median: | 1.78 | pixels |
fixed thresholds: | 0.0...25.0 | pixels |
N_data plotted: | 207 |
[click plot for closeup] |
This plot
These are the trending plots for the SINFONI QC parameters derived from the PSF calibration frames.
PSF standard star monitoring has been implemented beginning 2009-05-01.
The intent is to monitor the MINIMUM flux of the PSF star to insure that it has an adequate S/N.
Flux levels should be above 3 ADU/pixel within a 3 sigma aperture for the K and H+K-band.
In the case of the J and H-band PSF stars, the minimum allowed flux level is 2 ADU/pixel within a 3 sigma aperture.
The PSF standard star is often used to test the centering of science
exposures. Therefore, we monitor the radial offset from the nominal field
center: R = sqrt[ (x-x0)^2 + (y-y0)^2 ].
Find more information about SINFONI PSF calibration data
here.
Other QC parameters are also trended
here.
General information
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot.
If configured,
- data points belonging to the latest date are specially marked
- statistical averages are indicated by a solid line, and thresholds by broken lines
- outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
- "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
- you can download the data for each parameter set if the 'Data downloads' link shows up
|
