| SINFONI trending system: FULL report |
|
|
| Last update: 2019-06-28T05:11:36 (UT)
|
|
|
|
|
*Date on this monitor changes at 21:00 UT |
|
|
|
|
Plot
? |
Symb
? |
Source
* |
Average ? |
Thresholds ? |
N_
data |
QC1
parameter |
Data
downloads |
Remarks |
| method |
value |
unit |
method |
value |
| 1 |
• | QC1DB |
MEDIAN |
37.3 |
Pixels |
VAL | 30,45 |
179 |
qc_pupil_centerx |
all (full time range)
| X-centroid position of the sinfoni pupil (in pixels). The nominal value is at 32.5 pixels. |
| 2 |
o | QC1DB |
MEDIAN |
31.3 |
Pixels |
VAL | 23,38 |
179 |
qc_pupil_centery |
all (full time range)
| Y-centroid position of the sinfoni pupil (in pixels). The nominal value is at 32.5 pixels. |
| |
|
*Data sources: QC1DB: QC1 database; LOCAL: local data source
|
Plot 1
scores: not implemented
| | data source: | sinfoni_pupil
(QC1 database) |
| dataset: | qc_pupil_centerx | • |
| median: | 37.3 | Pixels |
| fixed thresholds: | 30...45 | Pixels |
| N_data plotted: | 179 |
| [click plot for closeup] |
Plot 2
scores: not implemented
| | data source: | sinfoni_pupil
(QC1 database) |
| dataset: | qc_pupil_centery | o |
| median: | 31.3 | Pixels |
| fixed thresholds: | 23...38 | Pixels |
| N_data plotted: | 179 |
| [click plot for closeup] |
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot.
If configured,
- data points belonging to the latest date are specially marked
- statistical averages are indicated by a solid line, and thresholds by broken lines
- outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
- "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
- you can download the data for each parameter set if the 'Data downloads' link shows up
|
