OMEGACAM trending system: HEALTH CHECK report

HELP

USERS-GUIDE

Last update: 2024-11-05T01:01:33 (UT)

| now: 2024-11-05T06:25:58 (UT)

muc06 QC pipeline: omega-1.1.9 (installed 2024-07-29)

same group:	TWILIGHT_level_uSDSS	gSDSS	rSDSS	iSDSS	zSDSS	BJOHN	VJOHN
same group:

General news:	NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
OMEGACAM news:
Report news:

DATE*: [?]

2024-10-29
report | NLT

2024-10-30
report | NLT

2024-10-31
report | NLT

2024-11-01
report | NLT

2024-11-02
report | NLT

2024-11-03
report | NLT

2024-11-04
report | NLT

r...

Raw CAL displays:

raw

P...

CAL product quality:

products

transfer

ngas

[?]

*Date on this monitor changes at 21:00 UT

png:	Information and research:
- png file	- advanced studies: QC1 browser \| QC1 plotter

Plot
?

Symb
?

Source
*

Average ?

Thresholds ?

N_
data

QC1
parameter

Data
downloads

Remarks

method

value

unit

method

value

•

QC1DB

MEDIAN

1.74e+04

ADU

VAL

10000.,55000.

qc_raw_twilight_median

this | last_yr | all

V_JOHN: median level in raw TWILIGHT flats averaged over all 32 detectors (ADU)

•

QC1DB

MEDIAN

1.72e+04

ADU

none

480

qc_raw_twilight_median

this | last_yr | all

V_JOHN: median level in raw TWILIGHT flats for each individual detector (ADU)

QC1DB

MEDIAN

1.59e+04

ADU

VAL

1000.,55000.

qc_raw_twilight_min

this | last_yr | all

V_JOHN: level of raw TWILIGHT flat with the minimum flux averaged over all detectors (ADU)

□

QC1DB

MEDIAN

1.85e+04

ADU

VAL

1000.,55000.

qc_raw_twilight_max

this | last_yr | all

V_JOHN: level of raw TWILIGHT flat with the maximum flux averaged over all detectors (ADU)

■

LOCAL

none

480

det_id

n/a

score per detector:
GREEN = within the thresholds

■

LOCAL

none

det_id

n/a

score per detector:
RED = beyond the thresholds

*Data sources: QC1DB: QC1 database; LOCAL: local data source

Plot 1 scores: 2\|
data source:	omegacam_twilight (QC1 database)
dataset:	qc_raw_twilight_median	•
median:	1.74e+04	ADU
fixed thresholds:	10000.0...55000.0	ADU
N_data plotted:	15
[click plot for closeup]

Plot 2 scores: not implemented
data source:	omegacam_twilight (QC1 database)
dataset:	qc_raw_twilight_median	•
median:	1.72e+04	ADU
thresholds:	none
N_data plotted:	480
[click plot for closeup]

Plot 3 scores: multiple dataset, cannot be scored
data source:	omegacam_twilight (QC1 database)
dataset: (numbers below apply to this dataset)	qc_raw_twilight_min	o
median:	1.59e+04	ADU
fixed thresholds:	1000.0...55000.0	ADU
N_data plotted:	15
[click plot for closeup]

Plot 4 scores: not implemented
data source:	local data source
dataset: (numbers below apply to this dataset)	det_id	■
average:	none
thresholds:	none
N_data plotted:	480
[click plot for closeup]

General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

data points belonging to the latest date are specially marked
statistical averages are indicated by a solid line, and thresholds by broken lines
outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
"aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
you can download the data for each parameter set if the 'Data downloads' link shows up
