KMOS trending system: HEALTH CHECK report
Last update: 2024-12-21T15:27:56 (UT)
[enable javascript for displaying time difference!]
General news:
NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
KMOS news:
Report news:
Plot? Symb? Source Average ? Thresholds ? N_ QC1 Data Remarks
method value unit method value
1
• QC1DB none K none 505 temp_spec1
this |
last_yr |
all
Temperature of spectrograph 1
2
• QC1DB none K none 505 temp_spec2
this |
last_yr |
all
Temperature of spectrograph 2
3
• QC1DB none K none 505 temp_spec3
this |
last_yr |
all
Temperature of spectrograph 3
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1 scores: not implemented
data source: kmos_flat dataset: temp_spec1 • average: none thresholds: none N_data plotted: 505 [click plot for closeup]
Plot 2 scores: not implemented
data source: kmos_flat dataset: temp_spec2 • average: none thresholds: none N_data plotted: 505 [click plot for closeup]
Plot 3 scores: not implemented
data source: kmos_flat dataset: temp_spec3 • average: none thresholds: none N_data plotted: 505 [click plot for closeup]
This plot
Temperature of spectrographs A, B, and C versus time, as recorded in the headers
of the flat-field exposures.
General information
Click on any of the plots to see a close-up version .
The latest date is indicated on top of the plot.
If configured,
data points belonging to the latest date are specially marked statistical averages are indicated by a solid line, and thresholds by broken lines outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ ↓ you can download the data for each parameter set if the 'Data downloads' link shows up
