GRAVITY trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2024-12-22T04:11:17 (UT)
  | now: 2024-12-22T06:23:49 (UT) muc05 QC pipeline: gravity-1.5.4 (installed 2022-03-24)
same group: dark_level dark_rms   badpix acqcam
General news: NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
GRAVITY news:
Report news: 2024-12-13 BIAS levels of SC_COMB_MED and SC_SPLI_MED were adjusted to avoid permanent red flags. The issue itself is still under investigation. [lschmidt@eso.org]
DATE*: [?] 2024-12-15
report | NLT 		2024-12-16
report | NLT 		2024-12-17
report | NLT 		2024-12-18
report | NLT 		2024-12-19
report | NLT 		2024-12-20
report | NLT 		2024-12-21
report | NLT
r...
Raw CAL displays:
raw raw raw raw raw raw raw
P...
CAL product quality:
products products products products products products products

transfer   ngas [?]

scores&comments | FULL | history ... | plot tutorial ... | contact | HC_docu... | quality events...                 daily/often; important to check     [?] 		*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?		 Symb
?		 Source
*		 Average ? Thresholds ? N_
data		 QC1
parameter		 Data
downloads		 Remarks
method value unit method value
1 •QC1DB MEDIAN 11.4 ADU VAL11.0,12.0 13 biasavg_sc this | last_yr | all mean bias level, LOW resolution, Science Camera (SC) detector, SPLIT polarisation, DIT=0.3 sec
2 •QC1DB MEDIAN 11.3 ADU VAL10.90,11.70 97 biasavg_sc this | last_yr | all mean bias level, MEDIUM resolution, Science Camera (SC) detector, SPLIT polarisation, DIT=0.3 sec
3 •QC1DB MEDIAN 17 ADU VAL16.65,17.45 14 biasavg_sc this | last_yr | all mean bias level, HIGH resolution, Science Camera (SC) detector, SPLIT polarisation, DIT=0.3 sec
4 •QC1DB MEDIAN -31.7 ADU VAL-55,-15 124 darklevel_ft this | last_yr | all mean dark level, Fringe Tracker (FT) detector, SPLIT polarisation, DIT=0.00085 sec
5 •QC1DB MEDIAN 21 ADU VAL20.6,21.6 3 biasavg_sc this | last_yr | all mean bias level, LOW resolution, Science Camera (SC) detector, COMBINED polarisation, DIT=0.3 sec
6 •QC1DB MEDIAN 20.7 ADU VAL20.40,21.00 63 biasavg_sc this | last_yr | all mean bias level, MEDIUM resolution, Science Camera (SC) detector, COMBINED polarisation, DIT=0.3 sec
7 •QC1DB MEDIAN 17 ADU VAL16.7,17.5 32 biasavg_sc this | last_yr | all mean bias level, HIGH resolution, Science Camera (SC) detector, COMBINED polarisation, DIT=0.3 sec
8 •QC1DB MEDIAN -28.8 ADU VAL-50,-10 98 darklevel_ft this | last_yr | all mean dark level, Fringe Tracker (FT) detector, COMBINED polarisation, DIT=0.00085 sec
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: 5|
data source:gravity_dark
(QC1 database)
dataset:biasavg_sc•
median:11.4ADU
fixed thresholds:11.0...12.0ADU
N_data plotted:13
[click plot for closeup]
Plot 2
scores: 13|
data source:gravity_dark
(QC1 database)
dataset:biasavg_sc•
median:11.3ADU
fixed thresholds:10.9...11.7ADU
N_data plotted:97
[click plot for closeup]
Plot 3
scores: 3|
data source:gravity_dark
(QC1 database)
dataset:biasavg_sc•
median:17ADU
fixed thresholds:16.65...17.45ADU
N_data plotted:14
[click plot for closeup]
Plot 4
scores: 20|
data source:gravity_dark
(QC1 database)
dataset:darklevel_ft•
median:-31.7ADU
fixed thresholds:-55...-15ADU
N_data plotted:124
[click plot for closeup]
Plot 5
scores: 3|
data source:gravity_dark
(QC1 database)
dataset:biasavg_sc•
median:21ADU
fixed thresholds:20.6...21.6ADU
N_data plotted:3
[click plot for closeup]
Plot 6
scores: 8|
data source:gravity_dark
(QC1 database)
dataset:biasavg_sc•
median:20.7ADU
fixed thresholds:20.4...21.0ADU
N_data plotted:63
[click plot for closeup]
Plot 7
scores: 5|
data source:gravity_dark
(QC1 database)
dataset:biasavg_sc•
median:17ADU
fixed thresholds:16.7...17.5ADU
N_data plotted:32
[click plot for closeup]
Plot 8
scores: 13|
data source:gravity_dark
(QC1 database)
dataset:darklevel_ft•
median:-28.8ADU
fixed thresholds:-50...-10ADU
N_data plotted:98
[click plot for closeup]
This plot

Trending plots for dark exposures of the Fringe Tracker (FT) and Science Camera (SC) detectors. Plotted are the dark level (FT), the bias level (SC), and the RMS of the master darks (both). The dark level is determined from the master dark whereas the bias is determined from the input raw frames and subtracted when creating the master in case of the SC detector.

The SC detector features a windowed read-out that depends on the spectral resolution (low, medium, or high) and on the polarimetry mode (splitted or combined). QC parameters from darks are only plotted for SC DITs of 0.3 sec and FT DITs of 0.00085 sec, respectively. For the dark level, only darks taken together with the P2VM calibrations are selected. These have FDDL WINDOW = 0.1 (only available since 2019-05-01 in the database).

General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
  • you can download the data for each parameter set if the 'Data downloads' link shows up
