NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
From a wavelength calibrated LSS arc lamp exposure, the mean spectral
resolution from all lines in the catalog is computed. Each single spectral
resolution is computed as the ratio between the arc lamp line wavelength
and its FWHM. The values trended here are for the blue sensitive EEV
detector, the 300V grism with no filter and a slit width of 0.29".
More information can be found on
the plot tutorial page
General information
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot.
If configured,
data points belonging to the latest date are specially marked
statistical averages are indicated by a solid line, and thresholds by broken lines
outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
"aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
you can download the data for each parameter set if the 'Data downloads' link shows up
