ESPRESSO trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2024-12-22T12:42:32 (UT)
  | now: 2024-12-22T17:53:01 (UT) muc11 QC pipeline: espdr-2.5.0 (installed 2022-06-28)
same group: reso_HR reso_UHR reso_MR
General news: NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
ESPRESSO news: These pages for ESPRESSO HC will be not be updated any longer after 21 Jan 2025. Please refer to the qcFlow generated Health Check.
Report news:
DATE*: [?] 2024-12-15
report | NLT 		2024-12-16
report | NLT 		2024-12-17
report | NLT 		2024-12-18
report | NLT 		2024-12-19
report | NLT 		2024-12-20
report | NLT 		2024-12-21
report | NLT
r...
Raw CAL displays:
raw raw raw raw raw raw raw
P...
CAL product quality:
products products products products products products products

transfer   ngas [?]

scores&comments | FULL | history ... | plot tutorial ... | contact | HC_docu... | quality events...               [?] 		*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?		 Symb
?		 Source
*		 Average ? Thresholds ? N_
data		 QC1
parameter		 Data
downloads		 Remarks
method value unit method value
1 •QC1DB MEDIAN   NONE VAL187000,200000 0 fiba_resol_med this | last_yr | all resolving power R, fibre A, 1x1 binning
3 •QC1DB MEDIAN 1.96e+05 NONE VAL195000,205000 19 fibb_resol_med this | last_yr | all resolving power R, fibre B, 1x1 binning
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: 2|
data source:espresso_wave_thar_a
(QC1 database)
dataset:fiba_resol_med•
median:no dataNONE
fixed thresholds:187000...200000NONE
N_data plotted:0
[click plot for closeup]
Plot 3
scores: 4|
data source:espresso_wave_thar_b
(QC1 database)
dataset:fibb_resol_med•
median:1.96e+05NONE
fixed thresholds:195000...205000NONE
N_data plotted:19
[click plot for closeup]
This plot

Trending plot for spectral resolving power R as measured with Th-Ar arc lines.

General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
  • you can download the data for each parameter set if the 'Data downloads' link shows up
