ESPRESSO trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2024-10-30T20:37:33 (UT)
  | now: 2024-10-31T06:06:58 (UT) muc11 QC pipeline: espdr-2.5.0 (installed 2022-06-28)
same group: reso_HR reso_UHR reso_MR
General news: NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
ESPRESSO news:
Report news:
DATE*: [?] 2024-10-24
report | NLT
2024-10-25
report | NLT
2024-10-26
report | NLT
2024-10-27
report | NLT
2024-10-28
report | NLT
2024-10-29
report | NLT
2024-10-30
report | NLT
r...
Raw CAL displays:
raw raw raw raw raw raw no CAL raw files
P...
CAL product quality:
products products products products products products no CAL products

transfer   ngas [?]

scores&comments | FULL | history ... | plot tutorial ... | contact | HC_docu... | quality events...               [?]
*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB MEDIAN 7.21e+04 NONE VAL65000,75000 13 fiba_resol_med this | last_yr | all resolving power R, fibre A, 4x2 binning
2 QC1DB MEDIAN 6.92e+04 NONE VAL65000,75000 13 fiba_resol_med this | last_yr | all resolving power R, fibre A, 8x4 binning
3 QC1DB MEDIAN 7.39e+04 NONE VAL65000,75000 13 fibb_resol_med this | last_yr | all resolving power R, fibre B, 4x2 binning
4 QC1DB MEDIAN 7.03e+04 NONE VAL65000,75000 13 fibb_resol_med this | last_yr | all resolving power R, fibre B, 8x4 binning
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: 1|
data source:espresso_wave_thar_a
(QC1 database)
dataset:fiba_resol_med
median:7.21e+04NONE
fixed thresholds:65000...75000NONE
N_data plotted:13
[click plot for closeup]
Plot 2
scores: 1|
data source:espresso_wave_thar_a
(QC1 database)
dataset:fiba_resol_med
median:6.92e+04NONE
fixed thresholds:65000...75000NONE
N_data plotted:13
[click plot for closeup]
Plot 3
scores: 1|
data source:espresso_wave_thar_b
(QC1 database)
dataset:fibb_resol_med
median:7.39e+04NONE
fixed thresholds:65000...75000NONE
N_data plotted:13
[click plot for closeup]
Plot 4
scores: 1|
data source:espresso_wave_thar_b
(QC1 database)
dataset:fibb_resol_med
median:7.03e+04NONE
fixed thresholds:65000...75000NONE
N_data plotted:13
[click plot for closeup]
This plot

Trending plot for spectral resolving power R as measured with Th-Ar arc lines.


General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
