Standard NACO reference frames

This is set of standard NACO calibration frames.

Find here the NACO calibration plan.

Reference frames:

IMAGING

SPECTROSCOPY

Standard NACO SPECTROSCOPY SW Lamp Flat Calibration Frames

camera+grismNo.+filter (SEQ.SPCMODE)	S27_2_SK	S27_3_SH	S27_3_SH	S27_3_SK	S27_4_SH	S54_2_SK	S54_3_SH	S54_3_SK	S54_4_SK	S54_4_SJ	S54_4_SHK
slit (INS.OPTI1.NAME)	FLM_13	FLM_13	slit_86mas	slit_172mas	slit_86mas	slit_172mas	slit_172mas	slit_86mas	slit_86mas	slit_86mas	slit_86mas
Read-out mode (DET.NCORRS.NAME- DET.MODE.NAME)	FNS-HS	FNS-HS	FNS-HS	FNS-HS	FNS-HS	FNS-HS	FNS-HS	FNS-HS	FNS-HS	FNS-HS	FNS-HS
Lamp ON
	2.6 Mb	2.6 Mb	4.2 Mb	2.6 Mb	2.6 Mb	2.6 Mb	2.6 Mb	4.2 Mb	4.2 Mb	2.6 Mb
	hdr	hdr	hdr	hdr	hdr	hdr	hdr	hdr	hdr	hdr	hdr
Lamp OFF
	2.6 Mb	2.6 Mb	4.2 Mb	2.6 Mb	2.6 Mb	2.6 Mb	2.6 Mb	2.6 Mb	4.2 Mb	4.2 Mb	2.6 Mb
	hdr	hdr	hdr	hdr	hdr	hdr	hdr	hdr	hdr	hdr	hdr

Standard NACO SPECTROSCOPY LW Lamp Flat Calibration Frames

camera+grismNo.+filter (SEQ.SPCMODE)	L27_1_L	L_27_1_Lprime	L54_1_SL	L54_2_Lprime
slit (INS.OPTI1.NAME)	slit_172mas	slit_86mas	slit_86mas	slit_172mas
Read-out mode (DET.NCORRS.NAME- DET.MODE.NAME)	FNS-HS	FNS-HS	FNS-HS	FNS-HS
Lamp ON
	2.6 Mb	2.6 Mb	2.6 Mb	2.6 Mb
	hdr	hdr	hdr	hdr
Lamp OFF
	2.6 Mb	2.6 Mb	2.6 Mb	2.6 Mb
	hdr	hdr	hdr	hdr

Standard NACO SPECTROSCOPY Arcs Calibration Frames

camera+grismNo.+filter (SEQ.SPCMODE)	S27_2_SK	S27_3_SH	S27_3_SK	S27_4_SH	S27_4_SJ	S54_2_SK	S54_3_SH	S54_3_SK	S54_4_SK	S54_4_SJ	S54_4_SHK	S54_3_H
slit (INS.OPTI1.NAME)	slit_86mas	slit_86mas	slit_172mas	slit_86mas	slit_172mas	slit_172mas	slit_172mas	slit_86mas	slit_86mas	slit_86mas	slit_86mas	slit_86mas
Read-out mode (DET.NCORRS.NAME- DET.MODE.NAME)	DCR-HD	DCR-HD	DCR-HD	DCR-HD	DCR-HD	DCR-HD	DCR-HD	DCR-HD	DCR-HD	DCR-HD	DCR-HD	DCR-HD
Arcs
	2.6 Mb	2.6 Mb	2.6 Mb	2.6 Mb	2.6 Mb	2.6 Mb	2.6 Mb	2.6 Mb	2.6 Mb	2.6 Mb	2.6 Mb	2.6 Mb
	hdr	hdr	hdr	hdr	hdr	hdr	hdr	hdr	hdr	hdr	hdr	hdr

Standard NACO PRISM SPECTROSCOPY Calibration Frames

camera+grismNo. (SEQ.SPCMODE)	S27_P1	S27_P1			camera+grismNo. (SEQ.SPCMODE)	S27_P1	S27_P1
slit (INS.OPTI1.NAME)	slit_172mas	slit_172mas			slit (INS.OPTI1.NAME)	slit_172mas	slit_172mas
Filter (INS.OPTI2.NAME)	CutOff_2.5um	CutOff_2.5um			Filter (INS.OPTI2.NAME)	open	CutOff_2.5um
Read-out mode (DET.NCORRS.NAME- DET.MODE.NAME)	DCR-HD	FNS-HS			Read-out mode (DET.NCORRS.NAME- DET.MODE.NAME)	DCR-HS	DCR-HS
Lamp ON					Arcs
	2.6 Mb	2.6 Mb				2.6 Mb	2.6 Mb
	hdr	hdr				hdr	hdr
Lamp OFF
	2.6 Mb	2.6 Mb
	hdr	hdr
