Plot
? |
Symb
? |
Source
* |
Average ? |
Thresholds ? |
N_
data |
QC1
parameter |
Data
downloads |
Remarks |
| method |
value |
unit |
method |
value |
| 1 |
• | QC1DB |
MEDIAN |
20.8 |
ADU |
OFF | ± 7 |
12 |
median_dark |
this |
last_yr |
all
|
median of master dark |
| 2 |
• | QC1DB |
MEDIAN |
3.59 |
ADU |
30% | ± 1.08 |
12 |
ron |
this |
last_yr |
all
|
&read out noise of raw dark |
| 3 |
• | QC1DB |
MEDIAN |
0.159 |
NONE |
VAL | 0.1,0.25 |
12 |
fp_norm |
this |
last_yr |
all
|
fixed-pattern noise of master dark |
| 4 |
• | QC1DB |
MEDIAN |
0.167 |
NONE |
VAL | 0.1,0.6 |
12 |
cosmic_rate |
this |
last_yr |
all
|
cosmic hit rate of dark per cm^2 |
| |
|
*Data sources: QC1DB: QC1 database; LOCAL: local data source
|
Plot 1
scores:  2|
| | data source: | xshooter_dark
(QC1 database) |
| dataset: | median_dark | • |
| median: | 20.8 | ADU |
| rel. thresholds: | 13.7607115...27.7607115 | ADU |
| N_data plotted: | 12 |
| [click plot for closeup] |
Plot 3
scores: 2|
| | data source: | xshooter_dark
(QC1 database) |
| dataset: | fp_norm | • |
| median: | 0.159 | NONE |
| fixed thresholds: | 0.1...0.25 | NONE |
| N_data plotted: | 12 |
| [click plot for closeup] |
Plot 2
scores: not implemented
| | data source: | xshooter_dark
(QC1 database) |
| dataset: | ron | • |
| median: | 3.59 | ADU |
| rel. thresholds: ±30% | 2.51164795...4.66448905 | ADU |
| N_data plotted: | 12 |
| [click plot for closeup] |
Plot 4
scores: 2|
| | data source: | xshooter_dark
(QC1 database) |
| dataset: | cosmic_rate | • |
| median: | 0.167 | NONE |
| fixed thresholds: | 0.1...0.6 | NONE |
| N_data plotted: | 12 |
| [click plot for closeup] |
Here we show various parameters for NIR dark frames: median level and
rms of the master dark, the cosmic ray hit rate (per second and unit
area), and the amplitude of the fixed pattern divided by the dark_med value.
For DIT=1.0, darks are acquired with NDIT=3, for all other DIT, darks are acquired with NDIT=1.
For DIT=5sec: from 2018-11 on darks are taken with NDIT=1, before with NDIT=5.
For more information see the
plot tutorial page.
