Plot
? |
Symb
? |
Source
* |
Average ? |
Thresholds ? |
N_
data |
QC1
parameter |
Data
downloads |
Remarks |
| method |
value |
unit |
method |
value |
| 1 |
• | QC1DB |
MEDIAN |
0.0064 |
fraction |
VAL | 0.0001,0.02 |
18 |
qc_ratiodome_rms |
this |
last_yr |
all
|
RATIODOMERMS, average over all 16 detectors |
| 2 |
• | QC1DB |
MEDIAN |
0.00606 |
fraction |
VAL | 0.0001,0.02 |
287 |
qc_ratiodome_rms |
this |
last_yr |
all
|
RATIODOMERMS, values of all detetcors |
| 3 |
• | QC1DB |
MEDIAN |
0.0036 |
fraction |
VAL | 0.0001,0.02 |
18 |
qc_ratiodome_rms |
this |
last_yr |
all
|
RATIODOMERMS, stdev over all detectors |
| 4 |
■ | LOCAL |
none |
|
fraction |
none | |
281 |
qc_ratiodome_rms |
n/a |
RATIODOMERMS, outlier detector |
| 4 |
■ | LOCAL |
none |
|
fraction |
none | |
7 |
qc_ratiodome_rms |
n/a |
RATIODOMERMS, outlier detector |
| |
|
*Data sources: QC1DB: QC1 database; LOCAL: local data source
|
Plot 1
scores:  4|
| | data source: | vircam_domeflat
(QC1 database) |
| dataset: | qc_ratiodome_rms | • |
| median: | 0.0064 | fraction |
| fixed thresholds: | 0.0001...0.02 | fraction |
| N_data plotted: | 18 |
| [click plot for closeup] |
Plot 2
scores: not implemented
| | data source: | vircam_domeflat
(QC1 database) |
| dataset: | qc_ratiodome_rms | • |
| median: | 0.00606 | fraction |
| fixed thresholds: | 0.0001...0.02 | fraction |
| N_data plotted: | 287 |
| [click plot for closeup] |
Plot 3
scores: 4|
| | data source: | vircam_domeflat
(QC1 database) |
| dataset: | qc_ratiodome_rms | • |
| median: | 0.0036 | fraction |
| fixed thresholds: | 0.0001...0.02 | fraction |
| N_data plotted: | 18 |
| [click plot for closeup] |
Plot 4
scores: not implemented
| | data source: | local data source
|
dataset:
(numbers below apply to this dataset) | qc_ratiodome_rms | ■ |
| average: | none |
| thresholds: | none |
| N_data plotted: | 281 |
| [click plot for closeup] |
The scoring thresholds of the individual chips used in box (4) are:
| CHIP_16 | 0.001 | 0.02 |
| CHIP_15 | 0.001 | 0.02 |
| CHIP_14 | 0.001 | 0.02 |
| CHIP_13 | 0.001 | 0.02 |
| CHIP_12 | 0.001 | 0.02 |
| CHIP_11 | 0.001 | 0.02 |
| CHIP_10 | 0.001 | 0.02 |
| CHIP_9 | 0.001 | 0.02 |
| CHIP_8 | 0.001 | 0.02 |
| CHIP_7 | 0.001 | 0.02 |
| CHIP_6 | 0.001 | 0.02 |
| CHIP_5 | 0.001 | 0.02 |
| CHIP_4 | 0.001 | 0.02 |
| CHIP_3 | 0.001 | 0.02 |
| CHIP_2 | 0.001 | 0.02 |
| CHIP_1 | 0.001 | 0.02 |
General information
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot.
If configured,
- data points belonging to the latest date are specially marked
- statistical averages are indicated by a solid line, and thresholds by broken lines
- outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
- "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
- you can download the data for each parameter set if the 'Data downloads' link shows up
|
