Plot
? |
Symb
? |
Source
* |
Average ? |
Thresholds ? |
N_
data |
QC1
parameter |
Data
downloads |
Remarks |
| method |
value |
unit |
method |
value |
| 1 |
• | QC1DB |
MEDIAN |
4.84e+03 |
ADU |
VAL | 4000,8000 |
18 |
qc_dome_medavg |
this |
last_yr |
all
|
DOMERAWAVG, average over all 16 detectors |
| 2 |
• | QC1DB |
MEDIAN |
4.87e+03 |
ADU |
VAL | 3000,14000 |
288 |
qc_dome_medavg |
this |
last_yr |
all
|
DOMERAWAVG, values of all detetcors |
| 3 |
• | QC1DB |
MEDIAN |
687 |
ADU |
VAL | 400,1500 |
18 |
qc_dome_medavg |
this |
last_yr |
all
|
DOMERAWAVG, stdev over all detectors |
| 4 |
■ | LOCAL |
none |
|
ADU |
none | |
288 |
qc_dome_medavg |
n/a |
|
| 4 |
■ | LOCAL |
none |
|
ADU |
none | |
0 |
qc_dome_medavg |
n/a |
DOMERAWAVG, outlier detector |
| |
|
*Data sources: QC1DB: QC1 database; LOCAL: local data source
|
Plot 1
scores:  4|
| | data source: | vircam_domeflat
(QC1 database) |
| dataset: | qc_dome_medavg | • |
| median: | 4.84e+03 | ADU |
| fixed thresholds: | 4000...8000 | ADU |
| N_data plotted: | 18 |
| [click plot for closeup] |
Plot 2
scores: not implemented
| | data source: | vircam_domeflat
(QC1 database) |
| dataset: | qc_dome_medavg | • |
| median: | 4.87e+03 | ADU |
| fixed thresholds: | 3000...14000 | ADU |
| N_data plotted: | 288 |
| [click plot for closeup] |
Plot 3
scores: 4|
| | data source: | vircam_domeflat
(QC1 database) |
| dataset: | qc_dome_medavg | • |
| median: | 687 | ADU |
| fixed thresholds: | 400...1500 | ADU |
| N_data plotted: | 18 |
| [click plot for closeup] |
Plot 4
scores: not implemented
| | data source: | local data source
|
dataset:
(numbers below apply to this dataset) | qc_dome_medavg | ■ |
| average: | none |
| thresholds: | none |
| N_data plotted: | 288 |
| [click plot for closeup] |
The scoring thresholds of the individual chips used in box (4) are:
| CHIP_16 | 3000 | 14000 |
| CHIP_15 | 3000 | 14000 |
| CHIP_14 | 3000 | 14000 |
| CHIP_13 | 3000 | 14000 |
| CHIP_12 | 3000 | 14000 |
| CHIP_11 | 3000 | 14000 |
| CHIP_10 | 3000 | 14000 |
| CHIP_9 | 3000 | 14000 |
| CHIP_8 | 3000 | 14000 |
| CHIP_7 | 3000 | 14000 |
| CHIP_6 | 3000 | 14000 |
| CHIP_5 | 3000 | 14000 |
| CHIP_4 | 3000 | 14000 |
| CHIP_3 | 3000 | 14000 |
| CHIP_2 | 3000 | 14000 |
| CHIP_1 | 3000 | 14000 |
General information
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot.
If configured,
- data points belonging to the latest date are specially marked
- statistical averages are indicated by a solid line, and thresholds by broken lines
- outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
- "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
- you can download the data for each parameter set if the 'Data downloads' link shows up
|
