Plot 1
scores:  7|
| | data source: | vimos_ifu_score
(QC1 database) |
| dataset: | Ne_flux | • |
| average: | none |
| fixed thresholds: | 140000.0...330000.0 | ADU/mm^2/s |
| N_data plotted: | 151 |
| [click plot for closeup] |
Plot 2
scores: 7|
| | data source: | vimos_ifu_score
(QC1 database) |
| dataset: | Ne_flux | • |
| average: | none |
| fixed thresholds: | 140000.0...400000.0 | ADU/mm^2/s |
| N_data plotted: | 151 |
| [click plot for closeup] |
Plot 3
scores: 7|
| | data source: | vimos_ifu_score
(QC1 database) |
| dataset: | Ne_flux | • |
| average: | none |
| fixed thresholds: | 50000.0...300000.0 | ADU/mm^2/s |
| N_data plotted: | 151 |
| [click plot for closeup] |
Plot 4
scores: 7|
| | data source: | vimos_ifu_score
(QC1 database) |
| dataset: | Ne_flux | • |
| average: | none |
| fixed thresholds: | 50000.0...280000.0 | ADU/mm^2/s |
| N_data plotted: | 151 |
| [click plot for closeup] |
Trending plot for the flux from selected arc lines.
This plot measures the performance of the arc lamps. Daytime measurements with
IFU HR_orange grism are used.
since Oct 2010: lamp flux problems, see PPRS-037215
Template ID: ifu_cal_DayCalib: Pipeline recipe: vmifucalib.
General information
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot.
If configured,
- data points belonging to the latest date are specially marked
- statistical averages are indicated by a solid line, and thresholds by broken lines
- outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
- "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
- you can download the data for each parameter set if the 'Data downloads' link shows up
|
