PIONIER trending system: HISTORY report
HELP USERS-GUIDE MORE
Last update: 2022-06-29T07:41:06 (UT)
same group: Bad_Pixels_science Gain_science   DARK Bad_Pixels Gain
close window history: 2014 2015   2016   2017 2018 2019 2020 2021 2022 2023 2024   HEALTH FULL
  ... ... ... ... ... ... ... ...
*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB MEDIAN 0.00537 ADU/px/s VAL-0,0.025 402 dark_med this | last_yr | all GRISM: High sensitivity
2 QC1DB MEDIAN 0.0042 ADU/px/s VAL-0,0.025 304 dark_med this | last_yr | all Medium sensitivity
3 QC1DB MEDIAN 0.00429 ADU/px/s VAL-0,0.025 1 dark_med this | last_yr | all
4 QC1DB MEDIAN 0.00139 ADU/px/s VAL-0.04,0.02 87 dark_med this | last_yr | all GRI+WOL: High sensitivity
5 QC1DB MEDIAN -0.00918 ADU/px/s VAL-0.04,0.02 92 dark_med this | last_yr | all FREE: High sensitivity
6 QC1DB MEDIAN   ADU/px/s VAL-0.04,0.02 0 dark_med this | last_yr | all Medium sensitivity
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
data source:pionier_dark
(QC1 database)
dataset:dark_med
median:0.00537ADU/px/s
fixed thresholds:0...0.025ADU/px/s
N_data plotted:402
[click plot for closeup]
Plot 2
data source:pionier_dark
(QC1 database)
dataset:dark_med
median:0.0042ADU/px/s
fixed thresholds:0...0.025ADU/px/s
N_data plotted:304
[click plot for closeup]
Plot 3
data source:pionier_dark
(QC1 database)
dataset:dark_med
median:0.00429ADU/px/s
fixed thresholds:0...0.025ADU/px/s
N_data plotted:1
[click plot for closeup]
Plot 4
data source:pionier_dark
(QC1 database)
dataset:dark_med
median:0.00139ADU/px/s
fixed thresholds:-0.04...0.02ADU/px/s
N_data plotted:87
[click plot for closeup]
Plot 5
data source:pionier_dark
(QC1 database)
dataset:dark_med
median:-0.00918ADU/px/s
fixed thresholds:-0.04...0.02ADU/px/s
N_data plotted:92
[click plot for closeup]
Plot 6
data source:pionier_dark
(QC1 database)
dataset:dark_med
median:no dataADU/px/s
fixed thresholds:-0.04...0.02ADU/px/s
N_data plotted:0
[click plot for closeup]
This plot

DARKs are taken once a day as day-time calibrations as well as at night within each OB.
The DARK taken within the night OB needs also to be monitor to ensure accurate calibration of the photometry.


General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
