NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
The pipeline produces QC parameters: QC.DET.FLUX.IP1, IP3,IP5, IP7.
In the OUT-OUT mode (these plots),
the beam1 corresponds to the QC parameter for IP1, beam2 for IP3, beam3 for IP5, beam4 for IP7
General information
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot.
If configured,
data points belonging to the latest date are specially marked
statistical averages are indicated by a solid line, and thresholds by broken lines
outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
"aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
you can download the data for each parameter set if the 'Data downloads' link shows up
