MATISSE trending system: FULL report
Last update: 2024-11-21T18:21:55 (UT)
[enable javascript for displaying time difference!]
General news:
NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
MATISSE news:
Report news:
Plot? Symb? Source Average ? Thresholds ? N_ QC1 Data Remarks
method value unit method value
1
• QC1DB none e-/ADU none 14 stdev_nonlin
all (full time range)
HAWAII-R2G (MATISSE-LM) - SCI-FAST-SPEED
2
• QC1DB none e-/ADU none 14 stdev_nonlin
all (full time range)
HAWAII-R2G (MATISSE-LM) - SCI-SLOW-SPEED
3
• QC1DB none e-/ADU none 45 stdev_nonlin
all (full time range)
AQUARIUS (MATISSE-N) - SCI-HIGH-GAIN
4
• QC1DB none e-/ADU none 3 stdev_nonlin
all (full time range)
AQUARIUS (MATISSE-N) - SCI-LOW-GAIN
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1 scores: not implemented
data source: matisse_detector dataset: stdev_nonlin • average: none thresholds: none N_data plotted: 14 [click plot for closeup]
Plot 2 scores: not implemented
data source: matisse_detector dataset: stdev_nonlin • average: none thresholds: none N_data plotted: 14 [click plot for closeup]
Plot 3 scores: not implemented
data source: matisse_detector dataset: stdev_nonlin • average: none thresholds: none N_data plotted: 45 [click plot for closeup]
Plot 4 scores: not implemented
data source: matisse_detector dataset: stdev_nonlin • average: none thresholds: none N_data plotted: 3 [click plot for closeup]
General information
Click on any of the plots to see a close-up version .
The latest date is indicated on top of the plot.
If configured,
data points belonging to the latest date are specially marked statistical averages are indicated by a solid line, and thresholds by broken lines outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ ↓ you can download the data for each parameter set if the 'Data downloads' link shows up
