GRAVITY trending system: HEALTH CHECK report
Last update: 2024-11-21T18:30:38 (UT)
[enable javascript for displaying time difference!]
General news:
NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
GRAVITY news:
Report news:
Plot? Symb? Source Average ? Thresholds ? N_ QC1 Data Remarks
method value unit method value
1
• QC1DB MEDIAN 12.6 pixel VAL 12.55,12.7 17 profile_center_sc1
this |
last_yr |
all
center of 1st flat-field profile, SPLIT polarisation
2
• QC1DB MEDIAN 161 pixel none 17 profile_center_sc13
this |
last_yr |
all
center of 13th flat-field profile, SPLIT polarisation
3
• QC1DB MEDIAN 0.592 pixel VAL 0.587,0.60 17 profile_width_sc1
this |
last_yr |
all
width of 1st flat-field profile, SPLIT polarisation
4
• QC1DB MEDIAN 0.537 pixel none 17 profile_width_sc13
this |
last_yr |
all
width of 13th flat-field profile, SPLIT polarisation
5
• QC1DB MEDIAN 18.6 pixel VAL 18.50,18.70 35 profile_center_sc1
this |
last_yr |
all
center of 1st flat-field profile, COMBINED polarisation
6
• QC1DB MEDIAN 315 pixel none 35 profile_center_sc13
this |
last_yr |
all
center of 13th flat-field profile, COMBINED polarisation
7
• QC1DB MEDIAN 0.589 pixel VAL 0.585,0.595 35 profile_width_sc1
this |
last_yr |
all
width of 1st flat-field profile, COMBINED polarisation
8
• QC1DB MEDIAN 0.548 pixel none 35 profile_width_sc13
this |
last_yr |
all
width of 13th flat-field profile, COMBINED polarisation
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1 scores: 2 |
data source: gravity_p2vm dataset: profile_center_sc1 • median: 12.6 pixel fixed thresholds: 12.55...12.7 pixel N_data plotted: 17 [click plot for closeup]
Plot 2 scores: not implemented
data source: gravity_p2vm dataset: profile_center_sc13 • median: 161 pixel thresholds: none N_data plotted: 17 [click plot for closeup]
Plot 3 scores: 2 |
data source: gravity_p2vm dataset: profile_width_sc1 • median: 0.592 pixel fixed thresholds: 0.587...0.6 pixel N_data plotted: 17 [click plot for closeup]
Plot 4 scores: not implemented
data source: gravity_p2vm dataset: profile_width_sc13 • median: 0.537 pixel thresholds: none N_data plotted: 17 [click plot for closeup]
Plot 5 scores: 1 |
data source: gravity_p2vm dataset: profile_center_sc1 • median: 18.6 pixel fixed thresholds: 18.5...18.7 pixel N_data plotted: 35 [click plot for closeup]
Plot 6 scores: not implemented
data source: gravity_p2vm dataset: profile_center_sc13 • median: 315 pixel thresholds: none N_data plotted: 35 [click plot for closeup]
Plot 7 scores: 1 |
data source: gravity_p2vm dataset: profile_width_sc1 • median: 0.589 pixel fixed thresholds: 0.585...0.595 pixel N_data plotted: 35 [click plot for closeup]
Plot 8 scores: not implemented
data source: gravity_p2vm dataset: profile_width_sc13 • median: 0.548 pixel thresholds: none N_data plotted: 35 [click plot for closeup]
This plot
Cross-dispersion profiles in flat fields: central position and width of the
1st and 13th profile.
General information
Click on any of the plots to see a close-up version .
The latest date is indicated on top of the plot.
If configured,
data points belonging to the latest date are specially marked statistical averages are indicated by a solid line, and thresholds by broken lines outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ ↓ you can download the data for each parameter set if the 'Data downloads' link shows up
