ERIS trending system: HEALTH CHECK report

HELP

USERS-GUIDE

Last update: 2024-11-22T06:09:03 (UT)

| now: 2024-11-22T09:19:11 (UT)

muc04 QC pipeline: eris-1.6.3 (installed 2024-08-30)

same group:		twilight_flat

General news:	NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
ERIS news:
Report news:

DATE*: [?]

2024-11-15
report | NLT

2024-11-16
report | NLT

2024-11-17
report | NLT

2024-11-18
report | NLT

2024-11-19
report | NLT

2024-11-20
report | NLT

2024-11-21
report | NLT

r...

Raw CAL displays:

raw

P...

CAL product quality:

products

products

transfer

ngas

[?]

scores&comments |

daily/often; important to check [?]

*Date on this monitor changes at 21:00 UT

png:	Information and research:
- png file	- advanced studies: QC1 browser \| QC1 plotter

Plot
?

Symb
?

Source
*

Average ?

Thresholds ?

N_
data

QC1
parameter

Data
downloads

Remarks

method

value

unit

method

value

•

QC1DB

MEDIAN

0.999

NONE

VAL

0.9911,1.0112

qc_flat_med_hi

this | last_yr | all

Median in slow readout

•

QC1DB

MEDIAN

0.0438

NONE

VAL

0.001,0.15

qc_flat_rms_hi

this | last_yr | all

rms in slow readout

•

QC1DB

MEDIAN

1.6e+04

NONE

VAL

10000,30000

qc_flat_on_med_max_hi

this | last_yr | all

maximum flux (on) in slow readout

•

QC1DB

MEDIAN

0.0749

NONE

VAL

0.0001,0.2

qc_flat_on_med_frac_hi

this | last_yr | all

Min/max flux (on) in slow readout

*Data sources: QC1DB: QC1 database; LOCAL: local data source

Plot 1 scores: 2\|
data source:	eris_nix_twilight_flat (QC1 database)
dataset:	qc_flat_med_hi	•
median:	0.999	NONE
fixed thresholds:	0.9911...1.0112	NONE
N_data plotted:	9
[click plot for closeup]

Plot 2 scores: 2\|
data source:	eris_nix_twilight_flat (QC1 database)
dataset:	qc_flat_rms_hi	•
median:	0.0438	NONE
fixed thresholds:	0.001...0.15	NONE
N_data plotted:	9
[click plot for closeup]

Plot 3 scores: 2\|
data source:	eris_nix_twilight_flat (QC1 database)
dataset:	qc_flat_on_med_max_hi	•
median:	1.6e+04	NONE
fixed thresholds:	10000...30000	NONE
N_data plotted:	9
[click plot for closeup]

Plot 4 scores: 2\|
data source:	eris_nix_twilight_flat (QC1 database)
dataset:	qc_flat_on_med_frac_hi	•
median:	0.0749	NONE
fixed thresholds:	0.0001...0.2	NONE
N_data plotted:	9
[click plot for closeup]

General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

data points belonging to the latest date are specially marked
statistical averages are indicated by a solid line, and thresholds by broken lines
outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
"aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
you can download the data for each parameter set if the 'Data downloads' link shows up
