ERIS trending system: HEALTH CHECK report

HELP

USERS-GUIDE

Last update: 2024-11-21T18:01:15 (UT)

| now: 2024-11-21T21:09:43 (UT)

muc04 QC pipeline: eris-1.6.3 (installed 2024-08-30)

same group:	dit=1.64	dit=10	dit=60	dit=300	dit=600	dit=900		dark_vs_dit
same group:

General news:	NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
ERIS news:
Report news:

DATE*: [?]

2024-11-14
report | NLT

2024-11-15
report | NLT

2024-11-16
report | NLT

2024-11-17
report | NLT

2024-11-18
report | NLT

2024-11-19
report | NLT

2024-11-20
report | NLT

r...

Raw CAL displays:

raw

P...

CAL product quality:

products

products

transfer

ngas

[?]

scores&comments |

daily/often; important to check [?]

*Date on this monitor changes at 21:00 UT

png:	Information and research:
- png file	- advanced studies: QC1 browser \| QC1 plotter

Plot
?

Symb
?

Source
*

Average ?

Thresholds ?

N_
data

QC1
parameter

Data
downloads

Remarks

method

value

unit

method

value

•

QC1DB

MEDIAN

1.24

ADU

VAL

-5,20

qc_masterdark_mean

this | last_yr | all

Clean mean of master dark level

•

QC1DB

MEDIAN

2.6

ADU

VAL

1.51,3.8

qc_masterdark_stdev

this | last_yr | all

Clean standard deviation of master dark

•

QC1DB

MEDIAN

2.37

ADU

VAL

1.32,3.45

qc_darkfpn

this | last_yr | all

fixed pattern noise

•

QC1DB

MEDIAN

1.37e+04

number

VAL

6600,21400

qc_dark_nbadpix

this | last_yr | all

number of bad pixels

•

QC1DB

MEDIAN

3.27e+04

ADU

VAL

31080,34350

qc_dark_n_nan

this | last_yr | all

number of pixels "nan" in the master dark

•

QC1DB

MEDIAN

0.00326

number

VAL

0.00158,0.00509

qc_dark_bpixfrac

this | last_yr | all

fraction of bad pixels in the master dark

*Data sources: QC1DB: QC1 database; LOCAL: local data source

Plot 1 scores: 9\|
data source:	eris_ifu_dark (QC1 database)
dataset:	qc_masterdark_mean	•
median:	1.24	ADU
fixed thresholds:	-5...20	ADU
N_data plotted:	74
[click plot for closeup]

Plot 2 scores: 9\|
data source:	eris_ifu_dark (QC1 database)
dataset:	qc_masterdark_stdev	•
median:	2.6	ADU
fixed thresholds:	1.51...3.8	ADU
N_data plotted:	74
[click plot for closeup]

Plot 3 scores: 9\|
data source:	eris_ifu_dark (QC1 database)
dataset:	qc_darkfpn	•
median:	2.37	ADU
fixed thresholds:	1.32...3.45	ADU
N_data plotted:	74
[click plot for closeup]

Plot 4 scores: 9\|
data source:	eris_ifu_dark (QC1 database)
dataset:	qc_dark_nbadpix	•
median:	1.37e+04	number
fixed thresholds:	6600...21400	number
N_data plotted:	74
[click plot for closeup]

Plot 5 scores: 9\|
data source:	eris_ifu_dark (QC1 database)
dataset:	qc_dark_n_nan	•
median:	3.27e+04	ADU
fixed thresholds:	31080...34350	ADU
N_data plotted:	74
[click plot for closeup]

Plot 6 scores: 9\|
data source:	eris_ifu_dark (QC1 database)
dataset:	qc_dark_bpixfrac	•
median:	0.00326	number
fixed thresholds:	0.00158...0.00509	number
N_data plotted:	74
[click plot for closeup]

This plot

The main qc parameters are plotted for the mostly used DITs

General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

data points belonging to the latest date are specially marked
statistical averages are indicated by a solid line, and thresholds by broken lines
outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
"aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
you can download the data for each parameter set if the 'Data downloads' link shows up
