Plot
? |
Symb
? |
Source
* |
Average ? |
Thresholds ? |
N_
data |
QC1
parameter |
Data
downloads |
Remarks |
| method |
value |
unit |
method |
value |
| 1 |
• | QC1DB |
MEDIAN |
-2.45 |
NONE |
VAL | -2.482,-2.442 |
88 |
tilt_global |
this |
last_yr |
all
|
tilt of the 0.2 slit, wlen_id=J1228 |
| 2 |
• | QC1DB |
MEDIAN |
-2.3 |
NONE |
VAL | -2.332,-2.292 |
33 |
tilt_global |
this |
last_yr |
all
|
tilt of the 0.4 slit, wlen_id=J1228 |
| |
|
*Data sources: QC1DB: QC1 database; LOCAL: local data source
|
Plot 1
scores: not implemented
| | data source: | criresp_wave
(QC1 database) |
| dataset: | tilt_global | • |
| median: | -2.45 | NONE |
| fixed thresholds: | -2.482...-2.442 | NONE |
| N_data plotted: | 88 |
| [click plot for closeup] |
Plot 2
scores: not implemented
| | data source: | criresp_wave
(QC1 database) |
| dataset: | tilt_global | • |
| median: | -2.3 | NONE |
| fixed thresholds: | -2.332...-2.292 | NONE |
| N_data plotted: | 33 |
| [click plot for closeup] |
Trending plot for the tilt of the slit determined from the CRIRES+
WAVE_FPET exposures.
Only the DPR.TYPE=WAVE,FPET wavelength calibrations in INS.WLEN.ID=J1228,
INS.SLIT1.WIDTH=0.2 and 0.4 arcsec, taken with metrology (OCS.MTRLGY.ST = T)
are selected.
General information
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot.
If configured,
- data points belonging to the latest date are specially marked
- statistical averages are indicated by a solid line, and thresholds by broken lines
- outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
- "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
- you can download the data for each parameter set if the 'Data downloads' link shows up
|
