CRIRES trending system: HISTORY report
HELP USERS-GUIDE MORE
Last update: 2012-10-14T03:46:42 (UT)
same group: xcorr ThAr N2O DISP RESOL   AVG
close window history: 2009 2010 2011   2012   2013   2014   HEALTH FULL
  ... ... ...
*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB MEDIAN 1e+05 none VAL75000,120000 114 resolution this | last_yr | all resolving power on chip2
2 QC1DB MEDIAN 1.07e+05 none VAL75000,125000 114 resolution this | last_yr | all resolving power on chip3
*Data sources: QC1DB: QC1 database; LOCAL: local text file
Plot 1
data source:crires_wave
(QC1 database)
dataset:resolution
median:1e+05none
fixed thresholds:75000...120000none
N_data plotted:114
[click on plot for closeup]
Plot 2
data source:crires_wave
(QC1 database)
dataset:resolution
median:1.07e+05none
fixed thresholds:75000...125000none
N_data plotted:114
[click on plot for closeup]
This plot

Wavelength calibration: trending of resolving power.

The resolvin power (lambda / Delta lambda) is monitored for the daily health check setting with reference wavelength (on chip 3) of 1090.4 nm which uses a ThAr lamp. It is determined from the median of the spectral lines identified on each detector.


General information

Click on any of the plots to see a close-up version. The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
