Plot
? |
Symb
? |
Source
* |
OPS?
** |
Average ? |
Thresholds ? |
N_
data |
QC1
parameter |
Data
downloads |
Remarks |
| method |
value |
unit |
method |
value |
| 1 |
• | QC1DB |
yes (0) |
MEDIAN |
0.1 |
ADU |
3SIG | ± 0.1282 |
8 |
FP_rA |
this |
last_yr |
all
|
4port readout, low gain (ABCD,1x1,low Garching) |
| 2 |
• | QC1DB |
yes (0) |
MEDIAN |
0.072 |
ADU |
3SIG | ± 0.17284 |
12 |
FP_rB |
this |
last_yr |
all
|
4port readout, low gain (ABCD,1x1,low Garching) |
| 4 |
• | QC1DB |
yes (0) |
MEDIAN |
0.084 |
ADU |
3SIG | ± 0.18415 |
13 |
FP_rC |
this |
last_yr |
all
|
4port readout, low gain (ABCD,1x1,low Garching) |
| 5 |
• | QC1DB |
yes (0) |
MEDIAN |
0.128 |
ADU |
3SIG | ± 0.18994 |
13 |
FP_rD |
this |
last_yr |
all
|
4port readout, low gain (ABCD,1x1,low Garching) |
| 6 |
• | QC1DB |
yes (0) |
MEDIAN |
0.03 |
ADU |
3SIG | ± 0.10914 |
6 |
FP_rA |
this |
last_yr |
all
|
1port readout, low gain (A,1x1,low Paranal) |
| 3 |
x | QC1DB |
yes (0) |
MEDIAN |
14.3 |
ADU |
3SIG | ± 5.51548 |
158 |
ins_focus_temp |
this |
last_yr |
all
|
Temperature at Instrument Focus |
| |
|
*Data sources: QC1DB: QC1 database; LOCAL: local text file | **OPS: to indicate that OPSLOG data are included
|
General information
Click on any of the plots to see a close-up version.
If applicable, the latest values from Paranal ops logs are plotted as blue dots. More information about those values, including a download option, is available in the OPS column.
The latest date is indicated on top of the plot, data points belonging to that date are specially marked.
If configured,
- statistical averages are indicated by a solid line, and thresholds by broken lines
- outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
- "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
- you can download the data for each parameter set if the 'Data downloads' link shows up
|
