VISIR trending system: HISTORY plot |
Last update: 2011-07-15T02:04:30 (UT)
|
|
|
*Date on this monitor changes at 21:00 UT |
|
|
|
Plot ? |
Symb ? |
Source * |
Average ? |
Thresholds ? |
N_ data |
QC1 parameter |
Data downloads |
Remarks |
method |
value |
unit |
method |
value |
1 |
| QC1DB |
MEAN |
1474.00415 |
mJy/1hr |
VAL | -10000,12000 |
82 |
backgd_mean |
this |
last_yr |
all
|
mean background for the SF, pfov=0.075 |
2 |
| QC1DB |
MEAN |
456.67691 |
mJy/1hr |
VAL | -10000,12000 |
14 |
backgd_mean |
this |
last_yr |
all
|
mean background for the IF, pfov=0.127 |
|
*Data sources: QC1DB: QC1 database; LOCAL: local text file
|
Plot 1 | data source: | visir_zp_img (QC1 database) |
dataset: | backgd_mean | |
mean: | 1474.00415 | mJy/1hr |
fixed thresholds: | -10000.0...12000.0 | mJy/1hr |
N_data plotted: | 82 |
[click on plot for closeup] |
Plot 2 | data source: | visir_zp_img (QC1 database) |
dataset: | backgd_mean | |
mean: | 456.67691 | mJy/1hr |
fixed thresholds: | -10000.0...12000.0 | mJy/1hr |
N_data plotted: | 14 |
[click on plot for closeup] |
This plot
Historical mean background values from imaging standard star observations
using the pre-upgrade detector.
Only data taken with the PAH1 filter are selected. The plot is separated
into small-field (SF) pixel field of view (0.075 arcsec/pixel) and
intermediate-field (IF) pixel field of view (0.127 arcsec/pixel).
The background level is determined from the half-cycle
frames where no offset correction (32768 value added for each pixel)
was applied.
General information
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot, data points belonging to that date are specially marked.
If configured,
- statistical averages are indicated by a solid line, and thresholds by broken lines
- outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
- "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
- you can download the data for each parameter set if the 'Data downloads' link shows up
|
