Plot
? |
Symb
? |
Source
* |
Average ? |
Thresholds ? |
N_
data |
QC1
parameter |
Data
downloads |
Remarks |
| method |
value |
unit |
method |
value |
| 1 |
• | QC1DB |
MEDIAN |
4.35043 |
e-/ADU |
none | |
633 |
qc_gain |
all (full time range)
| GAIN, average over all 16 detectors |
| 2 |
• | QC1DB |
MEDIAN |
4.15465 |
e-/ADU |
none | |
10053 |
qc_gain |
all (full time range)
| GAIN, values of all detetcors |
| 3 |
• | QC1DB |
MEDIAN |
0.604708 |
e-/ADU |
none | |
633 |
qc_gain |
all (full time range)
| GAIN, stdev over all detectors |
| |
|
*Data sources: QC1DB: QC1 database; LOCAL: local data source
|
Plot 1
scores: not implemented
| | data source: | vircam_gain
(QC1 database) |
| dataset: | qc_gain | • |
| median: | 4.35043 | e-/ADU |
| thresholds: | none | |
| N_data plotted: | 633 |
| [click plot for closeup] |
Plot 2
scores: not implemented
| | data source: | vircam_gain
(QC1 database) |
| dataset: | qc_gain | • |
| median: | 4.15465 | e-/ADU |
| thresholds: | none | |
| N_data plotted: | 10053 |
| [click plot for closeup] |
Plot 3
scores: not implemented
| | data source: | vircam_gain
(QC1 database) |
| dataset: | qc_gain | • |
| median: | 0.604708 | e-/ADU |
| thresholds: | none | |
| N_data plotted: | 633 |
| [click plot for closeup] |
The scoring thresholds of the individual chips used in box (4) are:
| CHIP_16 | 4.70 | 6.7 |
| CHIP_15 | 3.00 | 5.0 |
| CHIP_14 | 3.50 | 5.5 |
| CHIP_13 | 4.50 | 6.5 |
| CHIP_12 | 3.00 | 5.0 |
| CHIP_11 | 3.50 | 5.5 |
| CHIP_10 | 3.00 | 5.0 |
| CHIP_9 | 3.50 | 5.5 |
| CHIP_8 | 3.00 | 5.0 |
| CHIP_7 | 3.00 | 5.0 |
| CHIP_6 | 3.00 | 5.0 |
| CHIP_5 | 3.00 | 5.0 |
| CHIP_4 | 3.50 | 5.5 |
| CHIP_3 | 3.00 | 5.0 |
| CHIP_2 | 3.00 | 5.0 |
| CHIP_1 | 2.45 | 4.0 |
General information
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot.
If configured,
- data points belonging to the latest date are specially marked
- statistical averages are indicated by a solid line, and thresholds by broken lines
- outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
- "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
- you can download the data for each parameter set if the 'Data downloads' link shows up
|
