VIMOS trending system: HISTORY plot
Last update: 2009-02-04T16:06:30 (UT)
same group: median_master ron_master rms_master ron_raw median_vs_temp   averages_low averages_high
close window history: 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018   HEALTH
  ... ... ... ... ... ... ... ... ... ...
*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB MEDIAN 192.75 ADU VAL188,202 327 median_master this | last_yr | all average across all detectors, high gain
2 QC1DB MEDIAN 3.31244 ADU VAL3.1,3.6 327 noise_master this | last_yr | all average across all detectors, high gain
3 QC1DB MEDIAN 4.69042 ADU VAL0.5,10.0 327 median_master this | last_yr | all rms of average across all detectors, high gain
4 QC1DB MEDIAN 0.28846 ADU VAL0.15,0.50 327 noise_master this | last_yr | all rms of average across all detectors, high gain
*Data sources: QC1DB: QC1 database; LOCAL: local text file
This plot

Averages across all detectors for bias QC1 parameters.

The first row shows the average of Q1 to Q4 for the median bias level and the ron of the master frame (noise_master). The average is mainly sensitive to changes that affect all quadrants. The second row shows the rms across Q1 to Q4 for the QC parameters. This is mainly sensitive to changes that affect only one quadrant.


General information

Click on any of the plots to see a close-up version. The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
