SINFONI trending system: FULL report
HELP USERS-GUIDE MORE
Last update: 2019-06-28T05:15:13 (UT)
  | now: 2024-07-27T20:34:28 (UT) muc04 QC pipeline: sinfo-3.2.5 (installed 2019-05-09)
close window history: 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018   2019   HEALTH FULL
  ... ... ... ... ... ... ... ... ... ... ... ... ...
*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?		 Symb
?		 Source
*		 Average ? Thresholds ? N_
data		 QC1
parameter		 Data
downloads		 Remarks
method value unit method value
1 •QC1DB MEDIAN 400 ADU VAL380.0,420.0 1630 qc_frmdif_meanflux all (full time range) arc lamp (on - off) mean flux: J-band/250 mas camera scale
1 •QC1DB none   ADU none  231 qc_frmdif_meanflux all (full time range) arc lamp (on - off) mean flux: J-band/100 mas scale
1 •QC1DB none   ADU none  145 qc_frmdif_meanflux all (full time range) arc lamp (on - off) mean flux: J-band/ 25 mas scale
2 •QC1DB MEDIAN 116 ADU VAL95.0,135.0 1485 qc_frmdif_meanflux all (full time range) arc lamp (on - off) mean flux: H-band/250 mas camera scale
2 •QC1DB none   ADU none  420 qc_frmdif_meanflux all (full time range) arc lamp (on - off) mean flux: H-band/100 mas scale
2 •QC1DB none   ADU none  109 qc_frmdif_meanflux all (full time range) arc lamp (on - off) mean flux: H-band 25 mas scale
3 •QC1DB MEDIAN 149 ADU VAL140.0,190.0 1921 qc_frmdif_meanflux all (full time range) arc lamp (on - off) mean flux: K-band/250 mas camera scale
3 •QC1DB none   ADU none  1038 qc_frmdif_meanflux all (full time range) arc lamp (on - off) mean flux: K-band/100 mas scale
3 •QC1DB none   ADU none  528 qc_frmdif_meanflux all (full time range) arc lamp (on - off) mean flux: K-band/ 25 mas scale
4 •QC1DB MEDIAN 81.3 ADU VAL60.0,100.0 1750 qc_frmdif_meanflux all (full time range) arc lamp (on - off) mean flux: H+K-band/250 mas camera scale
4 •QC1DB none   ADU none  528 qc_frmdif_meanflux all (full time range) arc lamp (on - off) mean flux: H+K-band/100 mas scale
4 •QC1DB none   ADU none  589 qc_frmdif_meanflux all (full time range) arc lamp (on - off) mean flux: H+K-band/ 25 mas scale
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: not implemented
data source:sinfoni_wave
(QC1 database)
dataset:
(numbers below apply to this dataset)		qc_frmdif_meanflux•
median:400ADU
fixed thresholds:380.0...420.0ADU
N_data plotted:1630
[click plot for closeup]
Plot 2
scores: not implemented
data source:sinfoni_wave
(QC1 database)
dataset:
(numbers below apply to this dataset)		qc_frmdif_meanflux•
median:116ADU
fixed thresholds:95.0...135.0ADU
N_data plotted:1485
[click plot for closeup]
Plot 3
scores: not implemented
data source:sinfoni_wave
(QC1 database)
dataset:
(numbers below apply to this dataset)		qc_frmdif_meanflux•
median:149ADU
fixed thresholds:140.0...190.0ADU
N_data plotted:1921
[click plot for closeup]
Plot 4
scores: not implemented
data source:sinfoni_wave
(QC1 database)
dataset:
(numbers below apply to this dataset)		qc_frmdif_meanflux•
median:81.3ADU
fixed thresholds:60.0...100.0ADU
N_data plotted:1750
[click plot for closeup]
General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
  • you can download the data for each parameter set if the 'Data downloads' link shows up
