| SINFONI trending system: FULL report |
|
|
| Last update: 2019-06-28T05:14:20 (UT)
|
|
|
|
|
*Date on this monitor changes at 21:00 UT |
|
|
|
|
Plot
? |
Symb
? |
Source
* |
Average ? |
Thresholds ? |
N_
data |
QC1
parameter |
Data
downloads |
Remarks |
| method |
value |
unit |
method |
value |
| 1 |
• | QC1DB |
MEDIAN |
4.42 |
pixels |
VAL | 4.20,4.67 |
1630 |
qc_fwhm_med |
all (full time range)
| median FWHM of identified spectral lines in J-band at the 250 mas camera scale |
| 2 |
• | QC1DB |
MEDIAN |
3.22 |
pixels |
VAL | 3.02,3.42 |
1485 |
qc_fwhm_med |
all (full time range)
| median FWHM of identified spectral lines in the H-band at the 250 mas camera scale |
| 3 |
• | QC1DB |
MEDIAN |
1.98 |
pixels |
VAL | 1.80,2.40 |
1921 |
qc_fwhm_med |
all (full time range)
| median FWHM of identified spectral lines in the K-band at the 250 mas camera scale |
| 4 |
• | QC1DB |
MEDIAN |
2.48 |
pixels |
VAL | 2.29,2.69 |
1750 |
qc_fwhm_med |
all (full time range)
| median FWHM of identified spectral lines in the H+K-band at the 250 mas camera scale |
| |
|
*Data sources: QC1DB: QC1 database; LOCAL: local data source
|
Plot 1
scores: not implemented
| | data source: | sinfoni_wave
(QC1 database) |
| dataset: | qc_fwhm_med | • |
| median: | 4.42 | pixels |
| fixed thresholds: | 4.2...4.67 | pixels |
| N_data plotted: | 1630 |
| [click plot for closeup] |
Plot 2
scores: not implemented
| | data source: | sinfoni_wave
(QC1 database) |
| dataset: | qc_fwhm_med | • |
| median: | 3.22 | pixels |
| fixed thresholds: | 3.02...3.42 | pixels |
| N_data plotted: | 1485 |
| [click plot for closeup] |
Plot 3
scores: not implemented
| | data source: | sinfoni_wave
(QC1 database) |
| dataset: | qc_fwhm_med | • |
| median: | 1.98 | pixels |
| fixed thresholds: | 1.8...2.4 | pixels |
| N_data plotted: | 1921 |
| [click plot for closeup] |
Plot 4
scores: not implemented
| | data source: | sinfoni_wave
(QC1 database) |
| dataset: | qc_fwhm_med | • |
| median: | 2.48 | pixels |
| fixed thresholds: | 2.29...2.69 | pixels |
| N_data plotted: | 1750 |
| [click plot for closeup] |
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot.
If configured,
- data points belonging to the latest date are specially marked
- statistical averages are indicated by a solid line, and thresholds by broken lines
- outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
- "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
- you can download the data for each parameter set if the 'Data downloads' link shows up
|
