| SINFONI trending system: FULL report |
|
|
| Last update: 2019-06-28T05:10:08 (UT)
|
|
|
|
|
*Date on this monitor changes at 21:00 UT |
|
|
|
|
Plot
? |
Symb
? |
Source
* |
Average ? |
Thresholds ? |
N_
data |
QC1
parameter |
Data
downloads |
Remarks |
| method |
value |
unit |
method |
value |
| 1 |
• | QC1DB |
MEDIAN |
2.63 |
counts |
VAL | -20.0,20.0 |
451 |
qc_bpm_lin0_mean |
all (full time range)
| J-band linearity coefficient (mean) C0 (nlin(x) = C0 + C1x + C2x^2 + C3x^3) (only for the 25 mas camera scale) |
| 2 |
• | QC1DB |
MEDIAN |
0.888 |
counts |
VAL | -20.0,20.0 |
389 |
qc_bpm_lin0_mean |
all (full time range)
| H-band linearity coefficient (mean) C0 |
| 3 |
• | QC1DB |
MEDIAN |
-5.5 |
counts |
VAL | -20.0,20.0 |
535 |
qc_bpm_lin0_mean |
all (full time range)
| K-band linearity coefficient (mean) C0 |
| 4 |
• | QC1DB |
MEDIAN |
4.21 |
counts |
VAL | -20.0,20.0 |
485 |
qc_bpm_lin0_mean |
all (full time range)
| H+K-band linearity coefficient (mean) C0 |
| |
|
*Data sources: QC1DB: QC1 database; LOCAL: local data source
|
Plot 1
scores: not implemented
| | data source: | sinfoni_line
(QC1 database) |
| dataset: | qc_bpm_lin0_mean | • |
| median: | 2.63 | counts |
| fixed thresholds: | -20.0...20.0 | counts |
| N_data plotted: | 451 |
| [click plot for closeup] |
Plot 2
scores: not implemented
| | data source: | sinfoni_line
(QC1 database) |
| dataset: | qc_bpm_lin0_mean | • |
| median: | 0.888 | counts |
| fixed thresholds: | -20.0...20.0 | counts |
| N_data plotted: | 389 |
| [click plot for closeup] |
Plot 3
scores: not implemented
| | data source: | sinfoni_line
(QC1 database) |
| dataset: | qc_bpm_lin0_mean | • |
| median: | -5.5 | counts |
| fixed thresholds: | -20.0...20.0 | counts |
| N_data plotted: | 535 |
| [click plot for closeup] |
Plot 4
scores: not implemented
| | data source: | sinfoni_line
(QC1 database) |
| dataset: | qc_bpm_lin0_mean | • |
| median: | 4.21 | counts |
| fixed thresholds: | -20.0...20.0 | counts |
| N_data plotted: | 485 |
| [click plot for closeup] |
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot.
If configured,
- data points belonging to the latest date are specially marked
- statistical averages are indicated by a solid line, and thresholds by broken lines
- outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
- "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
- you can download the data for each parameter set if the 'Data downloads' link shows up
|
