SINFONI trending system: HISTORY report
HELP USERS-GUIDE MORE
Last update: 2014-01-15T03:30:27 (UT)
same group: HCAO
close window history: 2008 2009 2010 2011 2012   2013   2014   2015 2016 2017 2018 2019   HEALTH FULL
  ... ... ... ... ... ... ... ... ...
*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?		 Symb
?		 Source
*		 Average ? Thresholds ? N_
data		 QC1
parameter		 Data
downloads		 Remarks
method value unit method value
1 •QC1DB MEDIAN 0.808 unitless VAL0.7,1.0 132 qc_strehl_med this | last_yr | all median strehl ratio of fibre as computed over full K-band.
2 •QC1DB MEDIAN 0.777 unitless VAL0.7,1.0 132 qc_enc_core this | last_yr | all encircled energy within PSF core (normalized).
3 oQC1DB MEDIAN 0.885 unitless x 10-4 none  132 qc_strehl_mederr this | last_yr | all rms of median strehl ratio of fibre.
(this data set is NOT scored)
4 •QC1DB MEDIAN 25.1 counts VAL15.,35 132 qc_frmdif_meanflux this | last_yr | all average flux level in fibre frame extracted spectrum (counts).
*Data sources: QC1DB: QC1 database; LOCAL: local text file
Plot 1
data source:sinfoni_hcao
(QC1 database)
dataset:qc_strehl_med•
median:0.808unitless
fixed thresholds:0.7...1.0unitless
N_data plotted:132
[click on plot for closeup]
Plot 2
data source:sinfoni_hcao
(QC1 database)
dataset:qc_enc_core•
median:0.777unitless
fixed thresholds:0.7...1.0unitless
N_data plotted:132
[click on plot for closeup]
Plot 3
data source:sinfoni_hcao
(QC1 database)
dataset:qc_strehl_mederro
median:0.885unitless x 10-4
thresholds:none
N_data plotted:132
[click on plot for closeup]
Plot 4
data source:sinfoni_hcao
(QC1 database)
dataset:qc_frmdif_meanflux•
median:25.1counts
fixed thresholds:15.0...35counts
N_data plotted:132
[click on plot for closeup]
General information

Click on any of the plots to see a close-up version. The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
  • you can download the data for each parameter set if the 'Data downloads' link shows up
