This plot shows the dark level and the readout noise for
three acquired dark calibration setups,
triggered by the daily HC batch (DET.NCORRS.NAME, DET.MODE.NAME, DET.DIT in sec).
Values with DET.WIN.NX = 1024 and DET.FRAM.TYPE = INT
are monitored only, meaning window read out mode and cube mode are excluded.
No selection on the camera (e.g. S13, S27, ...) is applied.
Double_ReadResetRead, HighSensitivity, 0.5
FowlerNsamp, HighSensitivity, 300.0
FowlerNSamp, HighSensitivity, 1.7892
General information
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot.
If configured,
data points belonging to the latest date are specially marked
statistical averages are indicated by a solid line, and thresholds by broken lines
outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
"aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
you can download the data for each parameter set if the 'Data downloads' link shows up
