ISAAC trending system: HISTORY report
Last update: 2011-12-30T20:35:41 (UT)
same group: GratingCheck NightAcq DayCalSlit
close window history: 2005 2006 2007 2008 2009 2010   2011   2012   2013   HEALTH
  ... ... ... ... ... ...
*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB MEDIAN 509.50006 PIXEL VAL505,513 36 qc_slit_x this | last_yr | all X-position before calibrations
1 oQC1DB none   PIXEL none   35 qc_slit_x this | last_yr | all X-position after calibrations
2 QC1DB MEDIAN 532.5 PIXEL VAL525,540 36 qc_slit_y this | last_yr | all Y-position before calibrations
2 oQC1DB none   PIXEL none   35 qc_slit_y this | last_yr | all Y-position after calibrations
3 QC1DB MEDIAN -89.95257 YES none   36 qc_slit_a this | last_yr | all Tilt angle before calibrations
3 oQC1DB none   DEGREE none   35 qc_slit_a this | last_yr | all Tilt angle after calibrations
4 QC1DB MEDIAN 5677652.0 ADU none   36 qc_slit_f this | last_yr | all Arc line flux before calibrations
4 oQC1DB none   ADU none   35 qc_slit_f this | last_yr | all Arc line flux after calibrations
*Data sources: QC1DB: QC1 database; LOCAL: local text file
Plot 1
data source:isaac_slit
(QC1 database)
dataset:
(numbers below apply to this dataset)
qc_slit_x
median:509.50006PIXEL
fixed thresholds:505.0...513.0PIXEL
N_data plotted:36
[click on plot for closeup]
Plot 2
data source:isaac_slit
(QC1 database)
dataset:
(numbers below apply to this dataset)
qc_slit_y
median:532.5PIXEL
fixed thresholds:525.0...540.0PIXEL
N_data plotted:36
[click on plot for closeup]
Plot 3
data source:isaac_slit
(QC1 database)
dataset:
(numbers below apply to this dataset)
qc_slit_a
median:-89.95257YES
thresholds:none
N_data plotted:36
[click on plot for closeup]
Plot 4
data source:isaac_slit
(QC1 database)
dataset:
(numbers below apply to this dataset)
qc_slit_f
median:5677652.0ADU
thresholds:none
N_data plotted:36
[click on plot for closeup]
This plot

This is the trending plot of the through slit images taken as part of the day time calibration sequence for spectroscopy.

This plot describes:
1. The x-position of the first slit image taken before the spectroscopic arc and flat frames (black) and the second slit image taken after the spectroscopic arc and flat frames (red).
2. The y-position of the slit images taken before (black) and after (red) the day time calibrations.
3. The tilt angle of the slit images taken before (black) and after (red) the day time calibrations.
4. The flux of the slit images taken before (black) and after (red) the day time calibrations.
5. slit/camera movement during day-time calibrations: AFTER minus BEFORE measurement of Fig.1.
6. slit/camera movement during day-time calibrations: AFTER minus BEFORE measurement of Fig.2.
7. slit/camera movement during day-time calibrations: AFTER minus BEFORE measurement of Fig.3.
8. The time between both slit images in the calobuild batch in days.
Note 1 hour = 0.08 days.

The purpose of this trending is to check if the camera and grating have been stable during the batch acquisition of day time calibrations. Find more information about ISAAC slit frames here.




General information

Click on any of the plots to see a close-up version. The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
