ISAAC trending system: HISTORY plot

ISAAC trending system: HISTORY plot

Last update: 2008-01-13T22:01:18 (UT)

same group:

Print:

Information and research:

- png file

- advanced studies: QC1 browser | QC1 plotter

2007-04-03: outliers are due to arc line identification failures, and not necessarily due to arc lamp failues. the QC value is not robust. This plot is still experimental.
2007-04-03: The CentralGratingLine monitors the 1.4097 mu Argon line in SW-MR daily ; these plots monitor both the Argon and the Xenon lamp using day and night time arcs calibrations. All available SW-LR setups are used.

Plot [info]	Symbol [info]	Source*	Average [info]			Thresholds [info]		N_data	Data downloads	Remarks
Plot [info]	Symbol [info]	Source*	method	value	unit	method	value	N_data	Data downloads	Remarks
1	[7]	`QC1DB`	`none`		`ADU`	`none`		`16`	this \| last_yr \| all	Argon arc line flux for SW, LR, SZ, 0.3 slit
1	[19]	`QC1DB`	`none`		`ADU`	`none`		`1`	this \| last_yr \| all	Argon arc line flux for SW, LR, SZ, 0.6 slit
1	•	`QC1DB`	`none`		`ADU`	`none`		`1`	this \| last_yr \| all	Argon arc line flux for SW, LR, SZ, 0.8 slit
1	♦	`QC1DB`	`MEDIAN`	`576910.000`	`ADU`	`none`		`1`	this \| last_yr \| all	Argon arc line flux for SW, LR, SZ, 1 slit
1	+	`QC1DB`	`none`		`ADU`	`none`		`1`	this \| last_yr \| all	Argon arc line flux for SW, LR, SZ, 1.5 slit
1	x	`QC1DB`	`none`		`ADU`	`none`		`1`	this \| last_yr \| all	Argon arc line flux for SW, LR, SZ, 2 slit
2	[7]	`QC1DB`	`none`		`ADU`	`none`		`1`	this \| last_yr \| all	Argon arc line flux for SW, LR, J, 0.3 slit
2	[19]	`QC1DB`	`none`		`ADU`	`none`		`0`	this \| last_yr \| all	Argon arc line flux for SW, LR, J, 0.6 slit
2	•	`QC1DB`	`none`		`ADU`	`none`		`5`	this \| last_yr \| all	Argon arc line flux for SW, LR, J, 0.8 slit
2	♦	`QC1DB`	`MEDIAN`	`3577881.500`	`ADU`	`none`		`16`	this \| last_yr \| all	Argon arc line flux for SW, LR, J, 1 slit
2	+	`QC1DB`	`none`		`ADU`	`none`		`0`	this \| last_yr \| all	Argon arc line flux for SW, LR, J, 1.5 slit
2	x	`QC1DB`	`none`		`ADU`	`none`		`0`	this \| last_yr \| all	Argon arc line flux for SW, LR, J, 2 slit
3	[7]	`QC1DB`	`none`		`ADU`	`none`		`1`	this \| last_yr \| all	Argon arc line flux for SW, LR, SH, 0.3 slit
3	[19]	`QC1DB`	`none`		`ADU`	`none`		`1`	this \| last_yr \| all	Argon arc line flux for SW, LR, SH, 0.6 slit
3	•	`QC1DB`	`none`		`ADU`	`none`		`6`	this \| last_yr \| all	Argon arc line flux for SW, LR, SH, 0.8 slit
3	♦	`QC1DB`	`MEDIAN`	`8663151.000`	`ADU`	`none`		`32`	this \| last_yr \| all	Argon arc line flux for SW, LR, SH, 1 slit
3	+	`QC1DB`	`none`		`ADU`	`none`		`1`	this \| last_yr \| all	Argon arc line flux for SW, LR, SH, 1.5 slit
3	x	`QC1DB`	`none`		`ADU`	`none`		`1`	this \| last_yr \| all	Argon arc line flux for SW, LR, SH, 2 slit
4	[7]	`QC1DB`	`none`		`ADU`	`none`		`7`	this \| last_yr \| all	Argon arc line flux for SW, LR, SK, 0.3 slit
4	[19]	`QC1DB`	`none`		`ADU`	`none`		`10`	this \| last_yr \| all	Argon arc line flux for SW, LR, SK, 0.6 slit
4	•	`QC1DB`	`none`		`ADU`	`none`		`6`	this \| last_yr \| all	Argon arc line flux for SW, LR, SK, 0.8 slit
4	♦	`QC1DB`	`MEDIAN`	`16947198.000`	`ADU`	`none`		`38`	this \| last_yr \| all	Argon arc line flux for SW, LR, SK, 1 slit
4	+	`QC1DB`	`none`		`ADU`	`none`		`0`	this \| last_yr \| all	Argon arc line flux for SW, LR, SK, 1.5 slit
4	x	`QC1DB`	`none`		`ADU`	`none`		`4`	this \| last_yr \| all	Argon arc line flux for SW, LR, SK, 2 slit
6	[7]	`QC1DB`	`none`		`ADU`	`none`		`1`	this \| last_yr \| all	Xenon arc line flux for SW, LR, J, 0.3 slit
6	[19]	`QC1DB`	`none`		`ADU`	`none`		`1`	this \| last_yr \| all	Xenon arc line flux for SW, LR, J, 0.6 slit
6	•	`QC1DB`	`none`		`ADU`	`none`		`8`	this \| last_yr \| all	Xenon arc line flux for SW, LR, J, 0.8 slit
6	♦	`QC1DB`	`MEDIAN`	`1271488.625`	`ADU`	`none`		`29`	this \| last_yr \| all	Xenon arc line flux for SW, LR, J, 1 slit
6	+	`QC1DB`	`none`		`ADU`	`none`		`0`	this \| last_yr \| all	Xenon arc line flux for SW, LR, J, 1.5 slit
6	x	`QC1DB`	`none`		`ADU`	`none`		`0`	this \| last_yr \| all	Xenon arc line flux for SW, LR, J, 2 slit
7	[7]	`QC1DB`	`none`		`ADU`	`none`		`1`	this \| last_yr \| all	Xenon arc line flux for SW, LR, SH, 0.3 slit
7	[19]	`QC1DB`	`none`		`ADU`	`none`		`1`	this \| last_yr \| all	Xenon arc line flux for SW, LR, SH, 0.6 slit
7	•	`QC1DB`	`none`		`ADU`	`none`		`6`	this \| last_yr \| all	Xenon arc line flux for SW, LR, SH, 0.8 slit
7	♦	`QC1DB`	`MEDIAN`	`340202.812`	`ADU`	`none`		`32`	this \| last_yr \| all	Xenon arc line flux for SW, LR, SH, 1 slit
7	+	`QC1DB`	`none`		`ADU`	`none`		`1`	this \| last_yr \| all	Xenon arc line flux for SW, LR, SH, 1.5 slit
7	x	`QC1DB`	`none`		`ADU`	`none`		`1`	this \| last_yr \| all	Xenon arc line flux for SW, LR, SH, 2 slit
8	[7]	`QC1DB`	`none`		`ADU`	`none`		`7`	this \| last_yr \| all	Xenon arc line flux for SW, LR, SK, 0.3 slit
8	[19]	`QC1DB`	`none`		`ADU`	`none`		`10`	this \| last_yr \| all	Xenon arc line flux for SW, LR, SK, 0.6 slit
8	•	`QC1DB`	`none`		`ADU`	`none`		`6`	this \| last_yr \| all	Xenon arc line flux for SW, LR, SK, 0.8 slit
8	♦	`QC1DB`	`MEDIAN`	`19748434.000`	`ADU`	`none`		`38`	this \| last_yr \| all	Xenon arc line flux for SW, LR, SK, 1 slit
8	+	`QC1DB`	`none`		`ADU`	`none`		`0`	this \| last_yr \| all	Xenon arc line flux for SW, LR, SK, 1.5 slit
8	x	`QC1DB`	`none`		`ADU`	`none`		`4`	this \| last_yr \| all	Xenon arc line flux for SW, LR, SK, 2 slit

*Data sources: QC1DB: QC1 database; LOCAL: local text file

This plot

This is the trending plot for the ISAAC arc lamp calibrations of the SW-arm, LR-grating only

The QC parameters are fluxes of selected arc lines. The purpose is to monitor long-term lamp aging effects. These plots describe:
1. Line flux of Argon 1.054810 mu (SW-LR-SZ). Slits are coded with different symbols.
2. Line flux of Argon 1.208810 mu (SW-LR-J). Slits are coded with different symbols.
3. Line flux of Argon 1.744926 mu (SW-LR-SH). Slits are coded with different symbols.
4. Line flux of Argon 2.313952 mu (SW-LR-SK). Slits are coded with different symbols.

5. For SW-LR-SZ no Xenon lamp spectra are acquired.
6. Line flux of Xenon 1.202994 mu (SW-LR-J). Slits are coded with different symbols.
7. Line flux of Xenon 1.510384 mu (SW-LR-SH). Slits are coded with different symbols.
8. Line flux of Xenon 2.380295 mu (SW-LR-SK). Slits are coded with different symbols.
Find more information about ISAAC QC parameters derived from arc lamp frames here.

General information

Click on any of the plots to see a close-up version. The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

statistical averages are indicated by a solid line, and thresholds by broken lines
outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
"aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
you can download the data for each parameter set if the 'Data downloads' link shows up
