| HAWKI trending system: HISTORY report |
|
|
|
Last update: 2014-07-15T07:01:22 (UT)
|
|
|
*Date on this monitor changes at 21:00 UT |
|
|
|
|
Plot
? |
Symb
? |
Source
* |
Average ? |
Thresholds ? |
N_
data |
QC1
parameter |
Data
downloads |
Remarks |
| method |
value |
unit |
method |
value |
| 1 |
• | QC1DB |
MEDIAN |
9.14 |
ADU |
OFF | ± 0.5 |
106 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 4, DIT=2.0 |
| 2 |
• | QC1DB |
MEDIAN |
8.43 |
ADU |
OFF | ± 0.5 |
107 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 3, DIT=2.0 |
| 3 |
• | QC1DB |
MEDIAN |
4.91 |
ADU |
OFF | ± 2.0 |
77 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 4, DIT=300 |
| 4 |
• | QC1DB |
MEDIAN |
5.69 |
ADU |
OFF | ± 2.0 |
77 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 3, DIT=300 |
| 5 |
• | QC1DB |
MEDIAN |
10.3 |
ADU |
OFF | ± 0.5 |
107 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 1, DIT=2.0 |
| 6 |
• | QC1DB |
MEDIAN |
9.06 |
ADU |
OFF | ± 0.5 |
107 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 2, DIT=2.0 |
| 7 |
• | QC1DB |
MEDIAN |
6.42 |
ADU |
OFF | ± 2.0 |
77 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 1, DIT=300 |
| 8 |
• | QC1DB |
MEDIAN |
5.46 |
ADU |
OFF | ± 2.0 |
77 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 2, DIT=300 |
| |
|
*Data sources: QC1DB: QC1 database; LOCAL: local text file
|
| Plot 5 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 10.3 | ADU |
| rel. thresholds: | 9.813314...10.813314 | ADU |
| N_data plotted: | 107 |
| [click on plot for closeup] |
| Plot 6 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 9.06 | ADU |
| rel. thresholds: | 8.561147...9.561147 | ADU |
| N_data plotted: | 107 |
| [click on plot for closeup] |
| Plot 2 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 8.43 | ADU |
| rel. thresholds: | 7.929184...8.929184 | ADU |
| N_data plotted: | 107 |
| [click on plot for closeup] |
| Plot 1 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 9.14 | ADU |
| rel. thresholds: | 8.64044...9.64044 | ADU |
| N_data plotted: | 106 |
| [click on plot for closeup] |
| Plot 7 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 6.42 | ADU |
| rel. thresholds: | 4.416858...8.416858 | ADU |
| N_data plotted: | 77 |
| [click on plot for closeup] |
| Plot 8 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 5.46 | ADU |
| rel. thresholds: | 3.457468...7.457468 | ADU |
| N_data plotted: | 77 |
| [click on plot for closeup] |
| Plot 4 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 5.69 | ADU |
| rel. thresholds: | 3.693306...7.693306 | ADU |
| N_data plotted: | 77 |
| [click on plot for closeup] |
| Plot 3 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 4.91 | ADU |
| rel. thresholds: | 2.90921...6.90921 | ADU |
| N_data plotted: | 77 |
| [click on plot for closeup] |
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot, data points belonging to that date are specially marked.
If configured,
- statistical averages are indicated by a solid line, and thresholds by broken lines
- outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
- "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
- you can download the data for each parameter set if the 'Data downloads' link shows up
|
|
