| HAWKI trending system: HISTORY report |
|
|
|
Last update: 2013-10-15T07:04:31 (UT)
|
|
|
*Date on this monitor changes at 21:00 UT |
|
|
|
|
Plot
? |
Symb
? |
Source
* |
Average ? |
Thresholds ? |
N_
data |
QC1
parameter |
Data
downloads |
Remarks |
| method |
value |
unit |
method |
value |
| 1 |
• | QC1DB |
MEDIAN |
9.22 |
ADU |
OFF | ± 0.5 |
105 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 4, DIT=2.0 |
| 2 |
• | QC1DB |
MEDIAN |
8.44 |
ADU |
OFF | ± 0.5 |
106 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 3, DIT=2.0 |
| 3 |
• | QC1DB |
MEDIAN |
4.55 |
ADU |
OFF | ± 2.0 |
75 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 4, DIT=300 |
| 4 |
• | QC1DB |
MEDIAN |
5.25 |
ADU |
OFF | ± 2.0 |
75 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 3, DIT=300 |
| 5 |
• | QC1DB |
MEDIAN |
10.3 |
ADU |
OFF | ± 0.5 |
106 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 1, DIT=2.0 |
| 6 |
• | QC1DB |
MEDIAN |
9.13 |
ADU |
OFF | ± 0.5 |
106 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 2, DIT=2.0 |
| 7 |
• | QC1DB |
MEDIAN |
5.85 |
ADU |
OFF | ± 2.0 |
75 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 1, DIT=300 |
| 8 |
• | QC1DB |
MEDIAN |
5.14 |
ADU |
OFF | ± 2.0 |
75 |
qc_ron12 |
this |
last_yr |
all
|
DARK ReadOut Noise from RAW1 and RAW2, chip 2, DIT=300 |
| |
|
*Data sources: QC1DB: QC1 database; LOCAL: local text file
|
| Plot 5 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 10.3 | ADU |
| rel. thresholds: | 9.847085...10.847085 | ADU |
| N_data plotted: | 106 |
| [click on plot for closeup] |
| Plot 6 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 9.13 | ADU |
| rel. thresholds: | 8.633536...9.633536 | ADU |
| N_data plotted: | 106 |
| [click on plot for closeup] |
| Plot 2 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 8.44 | ADU |
| rel. thresholds: | 7.944768...8.944768 | ADU |
| N_data plotted: | 106 |
| [click on plot for closeup] |
| Plot 1 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 9.22 | ADU |
| rel. thresholds: | 8.717135...9.717135 | ADU |
| N_data plotted: | 105 |
| [click on plot for closeup] |
| Plot 7 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 5.85 | ADU |
| rel. thresholds: | 3.85467...7.85467 | ADU |
| N_data plotted: | 75 |
| [click on plot for closeup] |
| Plot 8 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 5.14 | ADU |
| rel. thresholds: | 3.137718...7.137718 | ADU |
| N_data plotted: | 75 |
| [click on plot for closeup] |
| Plot 4 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 5.25 | ADU |
| rel. thresholds: | 3.2501915...7.2501915 | ADU |
| N_data plotted: | 75 |
| [click on plot for closeup] |
| Plot 3 | | data source: | hawki_dark
(QC1 database) |
| dataset: | qc_ron12 | • |
| median: | 4.55 | ADU |
| rel. thresholds: | 2.548343...6.548343 | ADU |
| N_data plotted: | 75 |
| [click on plot for closeup] |
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot, data points belonging to that date are specially marked.
If configured,
- statistical averages are indicated by a solid line, and thresholds by broken lines
- outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
- "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
- you can download the data for each parameter set if the 'Data downloads' link shows up
|
|
