ESPRESSO trending system: HEALTH CHECK report
HELP USERS-GUIDE MORE
Last update: 2024-12-22T20:06:18 (UT)
  | now: 2024-12-23T02:16:15 (UT) muc11 QC pipeline: espdr-2.5.0 (installed 2022-06-28)
same group: DRIFT_HR_1x1 DRIFT_HR_2x1
General news: NOTE: The Health Check and calChecker services are moved to qcFlow on an instrument by instrument basis. The current pages will not be updated any longer once the move has been finished.
ESPRESSO news: These pages for ESPRESSO HC will be not be updated any longer after 21 Jan 2025. Please refer to the qcFlow generated Health Check.
Report news:
DATE*: [?] 2024-12-16
report | NLT
2024-12-17
report | NLT
2024-12-18
report | NLT
2024-12-19
report | NLT
2024-12-20
report | NLT
2024-12-21
report | NLT
2024-12-22
report | NLT
r...
Raw CAL displays:
raw raw raw raw raw raw raw
P...
CAL product quality:
products products products products products products products

transfer   ngas [?]

scores&comments | history ... | plot tutorial ... | contact | HC_docu... | quality events...                 daily/often; important to check     [?]
*Date on this monitor changes at 21:00 UT
png: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
?
Symb
?
Source
*
Average ? Thresholds ? N_
data
QC1
parameter
Data
downloads
Remarks
method value unit method value
1 QC1DB MEDIAN 0.332 px VAL-10,10 91 fiba_drift_mean_blue this | last_yr | all pixel shift from ThAr_FP, blue chip
2 QC1DB MEDIAN 0.185 px VAL-5,5 91 fiba_drift_mean_red this | last_yr | all pixel shift from ThAr_FP, red chip
3 QC1DB MEDIAN 1.6 cm/s/h VAL-60,60 91 fiba_drift_mean_blue this | last_yr | all drift from ThAr_FP, blue chip
4 QC1DB MEDIAN 1.06 cm/s/h VAL-30,30 91 fiba_drift_mean_red this | last_yr | all drift from ThAr_FP, red chip
5 QC1DB MEDIAN 0.467 px VAL-10,10 91 fibb_drift_mean_blue this | last_yr | all pixel shift from FP_ThAr, blue chip
6 QC1DB MEDIAN 0.169 px VAL-5,5 91 fibb_drift_mean_red this | last_yr | all pixel shift from FP_ThAr, red chip
7 QC1DB MEDIAN 2.48 cm/s/h VAL-60,60 91 fibb_drift_mean_blue this | last_yr | all drift from FP_ThAr, blue chip
8 QC1DB MEDIAN 0.951 cm/s/h VAL-30,30 91 fibb_drift_mean_red this | last_yr | all drift from FP_ThAr, red chip
*Data sources: QC1DB: QC1 database; LOCAL: local data source
Plot 1
scores: not implemented
data source:espresso_wave_thar_a
(QC1 database)
dataset:fiba_drift_mean_blue
median:0.332px
fixed thresholds:-10...10px
N_data plotted:91
[click plot for closeup]
Plot 2
scores: not implemented
data source:espresso_wave_thar_a
(QC1 database)
dataset:fiba_drift_mean_red
median:0.185px
fixed thresholds:-5...5px
N_data plotted:91
[click plot for closeup]
Plot 3
scores: not implemented
data source:espresso_wave_thar_a
(QC1 database)
dataset:fiba_drift_mean_blue
median:1.6cm/s/h
fixed thresholds:-60...60cm/s/h
N_data plotted:91
[click plot for closeup]
Plot 4
scores: not implemented
data source:espresso_wave_thar_a
(QC1 database)
dataset:fiba_drift_mean_red
median:1.06cm/s/h
fixed thresholds:-30...30cm/s/h
N_data plotted:91
[click plot for closeup]
Plot 5
scores: not implemented
data source:espresso_wave_thar_b
(QC1 database)
dataset:fibb_drift_mean_blue
median:0.467px
fixed thresholds:-10...10px
N_data plotted:91
[click plot for closeup]
Plot 6
scores: not implemented
data source:espresso_wave_thar_b
(QC1 database)
dataset:fibb_drift_mean_red
median:0.169px
fixed thresholds:-5...5px
N_data plotted:91
[click plot for closeup]
Plot 7
scores: not implemented
data source:espresso_wave_thar_b
(QC1 database)
dataset:fibb_drift_mean_blue
median:2.48cm/s/h
fixed thresholds:-60...60cm/s/h
N_data plotted:91
[click plot for closeup]
Plot 8
scores: not implemented
data source:espresso_wave_thar_b
(QC1 database)
dataset:fibb_drift_mean_red
median:0.951cm/s/h
fixed thresholds:-30...30cm/s/h
N_data plotted:91
[click plot for closeup]
This plot

Trending plot for drift measurements.

These are wavelength calibrations that are measured typically during the afternoon with ThAr in one fibre and Fabry-Perot (FP) in the other fibre. The FP lines are compared to a reference (typically from the morning calibrations) and a shift in pixels is determined. This shift is converted into a radial velocity precision, 0.002 pixels correspond to 1 m/s, and devided by the time difference to the reference.

Plots 1, 2, 5, and 6 show the shift in pixels; plots 3, 4, 7, and 8 the converted values in cm/s/h. Only measurements where the time difference to the FP reference is at least one hour are plotted.

Downloaded values are always in pixels, the conversion to cm/s/h is done internally. Also all measurements are available including values where the time difference is less than one hour. This can be checked with the delta_time_fp column that has the time difference in fractions of day.


General information

Click on any of the plots to see a close-up version.

The latest date is indicated on top of the plot.

If configured,

  • data points belonging to the latest date are specially marked
  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
