Plot
? |
Symb
? |
Source
* |
Average ? |
Thresholds ? |
N_
data |
QC1
parameter |
Data
downloads |
Remarks |
| method |
value |
unit |
method |
value |
| 1 |
• | QC1DB |
MEDIAN |
0.583 |
ADU |
VAL | -0.5,1.5 |
90 |
darkmed |
this |
last_yr |
all
|
median dark level, chip 1, DIT=1 |
| 2 |
• | QC1DB |
MEDIAN |
0.833 |
ADU |
VAL | 0,2.5 |
90 |
darkmed |
this |
last_yr |
all
|
median dark level, chip 2, DIT=1 |
| 3 |
• | QC1DB |
MEDIAN |
0.583 |
ADU |
VAL | -0.5,2.0 |
90 |
darkmed |
this |
last_yr |
all
|
median dark level, chip 3, DIT=1 |
| 4 |
• | QC1DB |
MEDIAN |
0.667 |
ADU |
VAL | 0,2.0 |
90 |
darkmed |
this |
last_yr |
all
|
median dark level, chip 4, DIT=1 |
| 5 |
• | QC1DB |
MEDIAN |
9.43 |
ADU |
VAL | 0,20 |
93 |
darkmed |
this |
last_yr |
all
|
median dark level, chip 1, DIT=300 |
| 6 |
• | QC1DB |
MEDIAN |
22 |
ADU |
VAL | 8.5,40 |
93 |
darkmed |
this |
last_yr |
all
|
median dark level, chip 2, DIT=300 |
| 7 |
• | QC1DB |
MEDIAN |
14.6 |
ADU |
VAL | 4,37 |
93 |
darkmed |
this |
last_yr |
all
|
median dark level, chip 3, DIT=300 |
| 8 |
• | QC1DB |
MEDIAN |
11.6 |
ADU |
VAL | 0,35 |
93 |
darkmed |
this |
last_yr |
all
|
median dark level, chip 4, DIT=300 |
| |
|
*Data sources: QC1DB: QC1 database; LOCAL: local text file
|
| Plot 1 | | data source: | crires_dark
(QC1 database) |
| dataset: | darkmed | • |
| median: | 0.583 | ADU |
| fixed thresholds: | -0.5...1.5 | ADU |
| N_data plotted: | 90 |
| [click on plot for closeup] |
| Plot 2 | | data source: | crires_dark
(QC1 database) |
| dataset: | darkmed | • |
| median: | 0.833 | ADU |
| fixed thresholds: | 0...2.5 | ADU |
| N_data plotted: | 90 |
| [click on plot for closeup] |
| Plot 3 | | data source: | crires_dark
(QC1 database) |
| dataset: | darkmed | • |
| median: | 0.583 | ADU |
| fixed thresholds: | -0.5...2.0 | ADU |
| N_data plotted: | 90 |
| [click on plot for closeup] |
| Plot 4 | | data source: | crires_dark
(QC1 database) |
| dataset: | darkmed | • |
| median: | 0.667 | ADU |
| fixed thresholds: | 0...2.0 | ADU |
| N_data plotted: | 90 |
| [click on plot for closeup] |
| Plot 5 | | data source: | crires_dark
(QC1 database) |
| dataset: | darkmed | • |
| median: | 9.43 | ADU |
| fixed thresholds: | 0...20 | ADU |
| N_data plotted: | 93 |
| [click on plot for closeup] |
| Plot 6 | | data source: | crires_dark
(QC1 database) |
| dataset: | darkmed | • |
| median: | 22 | ADU |
| fixed thresholds: | 8.5...40 | ADU |
| N_data plotted: | 93 |
| [click on plot for closeup] |
| Plot 7 | | data source: | crires_dark
(QC1 database) |
| dataset: | darkmed | • |
| median: | 14.6 | ADU |
| fixed thresholds: | 4...37 | ADU |
| N_data plotted: | 93 |
| [click on plot for closeup] |
| Plot 8 | | data source: | crires_dark
(QC1 database) |
| dataset: | darkmed | • |
| median: | 11.6 | ADU |
| fixed thresholds: | 0...35 | ADU |
| N_data plotted: | 93 |
| [click on plot for closeup] |
Trending plot for the median level in CRIRES DARK exposures.
The trending shows median levels from DIT=1sec and DIT=300sec exposures for all
four chips.
General information
Click on any of the plots to see a close-up version.
The latest date is indicated on top of the plot, data points belonging to that date are specially marked.
If configured,
- statistical averages are indicated by a solid line, and thresholds by broken lines
- outliers are marked by a red asterisk. They are defined as data points outside the
threshold lines
- "aliens" (= data points outside the plot Y limits) are marked by a red arrow (↑ or ↓)
- you can download the data for each parameter set if the 'Data downloads' link shows up
|
