CRIRES trending system: HISTORY plot
Last update: 2008-10-12T03:31:08 (UT)
same group: darkmed ron_raw
close window history: 2007   2008   2009   2010 2011 2012 2013 2014   HEALTH FULL
  ... ... ... ... ...
*Date on this monitor changes at 21:00 UT
Print: Information and research:
- png file - advanced studies: QC1 browser | QC1 plotter
Plot
[info]
Symbol
[info]
Source* Average [info] Thresholds [info] N_data Data downloads Remarks
method value unit method value
1 QC1DB MEDIAN 0.41667 ADU 3SIG± 0.61335 83 this | last_yr | all median dark level, chip 1, DIT=1
2 QC1DB MEDIAN -5.66667 ADU 3SIG± 3.25684 83 this | last_yr | all median dark level, chip 2, DIT=1
3 QC1DB MEDIAN 0.77778 ADU 3SIG± 0.44119 83 this | last_yr | all median dark level, chip 3, DIT=1
4 QC1DB MEDIAN -1.58333 ADU 3SIG± 1.86066 83 this | last_yr | all median dark level, chip 4, DIT=1
5 QC1DB MEDIAN 3.10606 ADU 3SIG± 13.42490 99 this | last_yr | all median dark level, chip 1, DIT=300
6 QC1DB MEDIAN 10.55050 ADU 3SIG± 8.76896 99 this | last_yr | all median dark level, chip 2, DIT=300
7 QC1DB MEDIAN 8.90909 ADU 3SIG± 11.09989 99 this | last_yr | all median dark level, chip 3, DIT=300
8 QC1DB MEDIAN 0.81818 ADU 3SIG± 11.59635 99 this | last_yr | all median dark level, chip 4, DIT=300
*Data sources: QC1DB: QC1 database; LOCAL: local text file
This plot

Trending plot for the median level in CRIRES DARK exposures.

The trending shows median levels from DIT=1sec and DIT=300sec exposures for all four chips.




General information

Click on any of the plots to see a close-up version. The latest date is indicated on top of the plot, data points belonging to that date are specially marked.

If configured,

  • statistical averages are indicated by a solid line, and thresholds by broken lines
  • outliers are marked by a red asterisk. They are defined as data points outside the threshold lines
  • "aliens" (= data points outside the plot Y limits) are marked by a red arrow ( or )
  • you can download the data for each parameter set if the 'Data downloads' link shows up
